TPGE-M32 bushing TPGE-M32

Indice locale:
RRR104BORP
Numero di catalogo:
TPGE-M32
Codice EAN:
5901924533818
Produttore: TRYTYT
Wall thickness [mm]: 1-4
Color: Gray
Maximum operating temperature [°C]: 110
Prezzo:
7,86 €
gross / conf.
(inclusa IVA 23%)
1,57 € gross/pezzi
Consegna in 3 ore
fino a 4 settimane (giorni lavorativi)
Raccolta in 1h
Quantità conf.
(multiplo:
1
)
Aggiungi agli appunti
Stampa

Descrizione del prodotto

The TPGE rubber cable gland is a quick and easy to install element for routing cables through device enclosures, etc. TPGE, if necessary, can also be used as a plug for a hole with a transit function. TPGE as a cable gland ensures dust and water tightness of the housing in accordance with IP67. Most often used in electrical and hydraulic devices, means of transport, lighting fixtures, etc.

Dati tecnici

  • Wall thickness [mm]
    1-4
  • Maximum operating temperature [°C]
    110
  • Level of security
    IP67
  • Cable diameter [mm]
    15-20
  • PKWIU
    22.19.73.0
  • Color
    Gray
  • Material
    Neoprene
  • Pieces in the package
    5
  • Minimum operating temperature [°C]
    -40

Dettagli del produttore

  • Produttore
    TRYTYT Sp. z o.o.
  • Indirizzo
    43-382 Bielsko-Biała Horeszków 8 Polska
