LRS 9/7 pipe-box connector E03DK-07010300101

local index:
RRR061ERGO
Catalog No:
E03DK-07010300101
Manufacturer: ERGOM
Gross length: 0.15
short name: LRS 9/7
Gross width: 0.12
Price:
8,89 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

LRS 9/7 pipe-box connector

Technical data

  • Gross length
    0.15
  • Gross width
    0.12
  • PKWIU
    22.21.29.0
  • short name
    LRS 9/7
  • Gross height
    0.05

Other technical data

  • Degree of protection (IP)
    IP67
  • Revolving thread
    No
  • Type of connection
    Other
  • Thread length
    10 mm
  • With integrated holder
    No
  • Materiał uszczelki
    Other
  • Colour
    Black
  • Approved in combination with protective conduit UR
    No
  • Model
    Straight
  • Construction type
    External thread
  • Thread connection size
    PG9
  • One-piece
    No
  • Material screw gland
    Polyamide (PA)
  • Max. outer diameter hose
    10 mm
  • Approved in combination with protective conduit according to DIN EN 61386-23
    No

Bulk packaging

A kind of package Sztuka
Quantity 10 pcs.
Weight (kg) 0,093
Width (m) 0,010
Length (m) 0,010
Depth (m) 0,010
