Industrial cable gland IP68 M63 light gray 5 pcs 250152

local index:
RRR057HAUP
Catalog No:
250152
EAN code:
4011923556594
Manufacturer: HAUPA
Blade length [mm]: 66
Thread: M63
Color: Gray
Price:
14,16 €
gross / pkg.
(including VAT 23%)
2,83 € gross/pcs.
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pkg.
(multiplicity:
1
)
Add to clipboard
Print

Product description

SlimTop - Polyamide 6.6 industrial metric gland with gasket and locknut, unassembled.

Technical data

  • Blade length [mm]
    66
  • Color
    Gray
  • Level of security
    IP68
  • Pieces in the package
    5
  • Inner diameter [mm]
    63
  • Thread
    M63
  • Material
    Polyamide
  • Flange width [mm]
    48.8
  • Hole diameter [mm]
    55
  • Accurate color
    light gray

Other technical data

  • Thread type
    Metric
  • Thread length
    12 mm
  • Suitable for cable diameter
    32 ... 42 mm
  • Material quality
    Polyamide (PA)
  • Glass-fibre reinforced
    No
  • Shock resistant
    No
  • With locknut
    Yes
  • Multi seal area
    No
  • With strain relief
    No
  • Separable screw gland
    No
  • Pitch thread
    1.5 mm
  • Wrench width
    68 mm
  • Material
    Plastic
  • Halogen free
    Yes
  • Degree of protection (IP)
    IP68
  • Bend radius protection/trumpet flare
    No
  • Model
    Straight
  • Flat cable coupling
    No
  • Type of sealing
    Sealing ring
  • Operating temperature
    -40 ... 85 °C
