Application - Terminal end holders are used in systems of insulated overhead power cables. They are used to attach cables to the walls of buildings and poles using standard hooks. Pass-through holders are used for hanging insulated ASXSn overhead wires with cross-sections of 16-120 mm2 on standard hook bolts. Corner pass-through brackets are used to hang cables at an angle of up to 90 degrees.

Advantages:
→ end brackets are made of a special corrosion-resistant aluminum alloy,
→ pressure parts made of polyamide resistant to UV radiation and difficult weather conditions,
→ pass-through handles are made of hot-dip galvanized sheet or aluminum,
→ rubber inserts are resistant to UV radiation,
→ allow for suspension of wires with a cross-section of up to 120mm2.

End holder for connection 4x16-25 002912002
