Distribution block type EBR2 500V - EBR2 4-12/160

Click on the photo to enlarge

ERGOM

Distribution block type EBR2 500V - EBR2 4-12/160 R33RA-02020300501

Name: Distribution block type EBR2 500V - EBR2 4-12/160
Brand: ERGOM
SKU: RRR404ERGO
Price: 72.14 PLN
Availability: InStock

local index:

RRR404ERGO

Catalog No:

R33RA-02020300501

EAN code:

5900003721221

Price:

72,14 €

gross / pcs.

including VAT 23%

Availability:

Check availability in branches

In warehouses 34 pcs.

Delivery:

From 3,68 € (prepaid courier) Details

Estimated delivery time:

DHL, Inpost 1-3 working days

Delivery in 3h

Pickup in 1h

Quantity:

Goods at a promotional price can only be purchased in the quantity available in stock

pcs.

It is not possible to add more of this product to the cart. Goods at a promotional price can only be purchased in the quantity available in stock.

Delivery methods:

details

Payment methods:

details

Go to section:

Product description Technical data

Product description

Distribution block type EBR2 500V - EBR2 4-12/160 from the manufacturer ERGOM. The product catalog number is < strong>R33RA-02020300501.

Mounting: on TSE 35 rail or by screws to the substrate (2 Ø5 holes).
Clamp hole diameter (for 1 track) [mm]: 1x11.5+3x8.5+8x7.
Cross-sections of connected wires - strands without endings (for 1 track): 1x10÷50+3x6÷25 +8x1.5÷16.
Cross-sections of connected cables - cables with HI termination (for 1 track): 1x10÷50+3x10÷35+8x2.5÷16.
Rated continuous current In 40°C [A]: 160.
Ipk [kA]: 20.
Transparent cover for optical control of the condition of the wires polycarbonate covers between the strips .
Application: LV switchboards.

Report an error

Technical data

Length [mm]

85
Material

PC
Tightening torque [Nm]

2
Clamp type

Threaded
Height [mm]

70

Number of tracks

4
conductive material

Brass
Rated insulation voltage [V]

500
Width [mm]

170
Insulation material

Polyamide

Other technical data

Height

85 mm
Depth

70 mm
Number of poles

4
Conductor cross section solid (solid, stranded)

1.5 ... 50 mm²

Width

175 mm
Max. rated current

160 A
Conductor cross section flexible (fine-strand) with cable end sleeve

1.5 ... 50 mm²
Number of clamp positions per pole

12
