Choke V-TEC VM M63X1.5 J.SZ V-TEC VM63 LGR 2022876

Índice local:
RRR400OBOB
Número de catálogo:
2022876
Código EAN:
4012195533955
Fabricante: OBO BETTERMANN
Color: Gray
Handle: M63x1.5
Accurate color: light gray
Precio:
24,78 zł
gross / uds.
(IVA incluido 23%)
Accesible 73 uds.
Recogida en 1h
Cantidad uds.
(múltiple:
1
)
Añadir a solicitud de presupuesto
Añadir al portapapeles
Imprimir

Descripción del producto

Robust cable gland with metric thread according to IEC 423 with a cap nut design that guarantees high tightness. Strain relief, anti-twist protection and tightness over the entire clamping area. Polychloroprene/ABS rubber sealing ring. Spray-on seal on the adapter, no need for a thread seal ring, VDE approved according to DIN EN 50262, IP68 protection at 5 bar/1h. Operating temperature range -20°C to +65°C.

Datos técnicos

  • Color
    Gray
  • Accurate color
    light gray
  • Handle
    M63x1.5
  • PKWIU
    22.29.29.0

Otros datos técnicos

  • Thread type
    Metric
  • Pitch thread
    1.5 mm
  • Wrench width
    67 mm
  • Suitable for cable diameter
    36 ... 48 mm
  • Material quality
    Polyamide (PA)
  • Glass-fibre reinforced
    No
  • Shock resistant
    No
  • RAL-number
    7035
  • With locknut
    No
  • Multi seal area
    No
  • With strain relief
    Yes
  • Separable screw gland
    No
  • Explosion-tested version
    No
  • For Ex-Zone dust
    None
  • Nominal thread size metric/PG
    63
  • Thread length
    12 mm
  • Hexagon angular dimension
    75 mm
  • Material
    Plastic
  • Halogen free
    Yes
  • Degree of protection (IP)
    IP68
  • Colour
    Grey
  • Bend radius protection/trumpet flare
    No
  • Model
    Straight
  • Flat cable coupling
    No
  • Type of sealing
    Sealing ring
  • Operating temperature
    -20 ... 65 °C
  • For Ex-zone gas
    None

Detalles del fabricante

  • Fabricante
    OBO Bettermann Holding GmbH & Co. KG
  • Dirección
    58710 Menden Hüingser Ring 52 Niemcy

Empaquetado a granel

una especie de paquete Skrzynia Karton Paleta
Cantidad 5 uds. 60 uds. 960 uds.
Peso (kg) 0,507 6,673 129,268
Volumen (m3) 0,003 0,044 0,912
Ancho (m) 0,138 0,288 0,800
Longitud (m) 0,188 0,395 1,200
Profundidad (m) 0,116 0,383 0,950
