Choke V-TEC VM M16X1.5 J.SZ. 2022864

local index:
RRR079OBOB
Catalog No:
2022864
EAN code:
4012195533238
Manufacturer: OBO BETTERMANN
Color: Gray
Handle: M16x1.5
Accurate color: light gray
Price:
0,59 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Accessible 1271 pcs.
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Robust cable gland with metric thread according to IEC 423 with a cap nut design that guarantees high tightness. Strain relief, anti-twist protection and tightness over the entire clamping area. Polychloroprene/ABS rubber sealing ring. Spray-on seal on the adapter, no need for a thread seal ring, VDE approved according to DIN EN 50262, IP68 protection at 5 bar/1h. Operating temperature range -20°C to +65°C.

Technical data

  • Color
    Gray
  • Accurate color
    light gray
  • Handle
    M16x1.5
  • PKWIU
    22.29.29.0

Bulk packaging

A kind of package Skrzynia Karton Paleta
Quantity 50 pcs. 500 pcs. 24000 pcs.
Weight (kg) 0,373 4,008 214,884
Volume (m3) 0,001 0,014 0,912
Width (m) 0,093 0,185 0,800
Length (m) 0,134 0,295 1,200
Depth (m) 0,086 0,249 0,950
