Busbar S12 1F -10 45.102

local index:
RPU002ELOP
Catalog No:
45.102
EAN code:
5901769010581
Length [mm]: 210
Number of tracks: 1F
cross section [mm²]: 10
Price:
2,48 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 4 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

One and three-way. Easy-to-install insulated copper busbars are suitable for connecting switches and electrical devices of the "S" type.

Technical data

  • Length [mm]
    210
  • cross section [mm²]
    10
  • PKWIU
    27.12.40.0
  • Number of tracks
    1F
  • Current [A]
    63

Other technical data

  • Number of phases
    1
  • Suitable for number of devices
    12
  • Cross section
    10 mm²
  • Rated permanent current Iu
    63 A
  • Insulated
    Yes
  • Max. rated operation voltage Ue
    400 V
  • Suitable for devices with N-conductor
    No
  • Number of poles
    1
  • Module width
    17.8 mm
  • Length
    210 mm
  • Type of electric connection
    Fork
  • Rated surge voltage
    2.5 kV
  • Rated short-time withstand current lcw
    0.063 kA
  • Suitable for devices with auxiliary switch
    No

Bulk packaging

A kind of package Sztuka
Quantity 1 pcs. 1 pcs.
Weight (kg) 0,048 -
