Switchboards and enclosures
Switchgear accessories
Brass cable gland IP68 PG9 nickel-plated 10 pcs 250632
local index:
RRR095HAUP
Catalog No:
250632
EAN code:
4011923561673
Click on the photo to enlarge
Manufacturer:
HAUPA
Blade length [mm]:
17
Thread:
PG9
Material:
Brass
See full description
Price:
14,76 €
gross / pkg.
(including VAT 23%)
1,48 € gross/pcs.
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pkg.
(multiplicity:
1
)
Add to cart
Add to clipboard
Print
Ask about the product
Product description
Technical data
Product description
Cable glands made of nickel-plated brass, with gasket and locknut, fully assembled.
Technical data
Blade length [mm]
17
Material
Brass
Flange width [mm]
8.5
Hole diameter [mm]
11.8
Thread
PG9
Level of security
IP68
Pieces in the package
10
Inner diameter [mm]
14.8
Other technical data
Thread type
PG
Thread length
8.1 mm
Suitable for cable diameter
4 ... 8 mm
Material quality
Brass
Degree of protection (IP)
IP68
With locknut
Yes
Multi seal area
No
With strain relief
Yes
Separable screw gland
Yes
Pitch thread
1.5 mm
Wrench width
17 mm
Material
Metal
Halogen free
Yes
Bend radius protection/trumpet flare
No
Model
Straight
Flat cable coupling
No
Type of sealing
Sealing ring
Operating temperature
-30 ... +120 °C
