Brass cable gland IP68 PG7 nickel-plated 10 pcs 250630

local index:
RRR094HAUP
Catalog No:
250630
EAN code:
4011923561666
Manufacturer: HAUPA
Blade length [mm]: 14
Thread: PG7
Material: Brass
Price:
11,54 €
gross / pkg.
(including VAT 23%)
1,15 € gross/pcs.
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pkg.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Cable glands made of nickel-plated brass, with gasket and locknut, fully assembled.

Technical data

  • Blade length [mm]
    14
  • Material
    Brass
  • Flange width [mm]
    6.9
  • Hole diameter [mm]
    8.5
  • Thread
    PG7
  • Level of security
    IP68
  • Pieces in the package
    10
  • Inner diameter [mm]
    12

Other technical data

  • Thread type
    PG
  • Thread length
    6.5 mm
  • Suitable for cable diameter
    3 ... 6.5 mm
  • Material quality
    Brass
  • Degree of protection (IP)
    IP68
  • With locknut
    Yes
  • Multi seal area
    No
  • With strain relief
    Yes
  • Separable screw gland
    Yes
  • Pitch thread
    1.5 mm
  • Wrench width
    14 mm
  • Material
    Metal
  • Halogen free
    Yes
  • Bend radius protection/trumpet flare
    No
  • Model
    Straight
  • Flat cable coupling
    No
  • Type of sealing
    Sealing ring
  • Operating temperature
    -30 ... +120 °C
