Brass cable gland IP68 M40 45mm nickel-plated 5 pcs 250611

local index:
RRR083HAUP
Catalog No:
250611
EAN code:
4011923568054
Manufacturer: HAUPA
Blade length [mm]: 45
Thread: M40
Material: Brass
Price:
44,22 €
gross / pkg.
(including VAT 23%)
8,84 € gross/pcs.
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pkg.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Cable glands made of nickel-plated brass, with gasket and locknut, fully assembled.

Technical data

  • Blade length [mm]
    45
  • Material
    Brass
  • Flange width [mm]
    30.5
  • Hole diameter [mm]
    35
  • Thread
    M40
  • Level of security
    IP68
  • Pieces in the package
    5
  • Inner diameter [mm]
    40

Other technical data

  • Thread type
    Metric
  • Thread length
    11 mm
  • Suitable for cable diameter
    22 ... 30 mm
  • Material quality
    Brass
  • Colour
    Other
  • Model
    Straight
  • Flat cable coupling
    No
  • Type of sealing
    Sealing ring
  • Operating temperature
    -40 ... +120 °C
  • Pitch thread
    1.5 mm
  • Wrench width
    45 mm
  • Material
    Metal
  • Degree of protection (IP)
    IP68
  • With locknut
    Yes
  • Multi seal area
    No
  • With strain relief
    Yes
  • Separable screw gland
    No
