el12 Running cables and wires Channels Metal channels Tray, KOJ100H60/3 N
Tray, KOJ100H60/3 N
Tray, KOJ100H60/3 N
Tray, KOJ100H60/3 N
Tray, KOJ100H60/3 N
Tray, KOJ100H60/3 N
Tray, KOJ100H60/3 N
Tray, KOJ100H60/3 N
Tray, KOJ100H60/3 N
Tray, KOJ100H60/3 N
Tray, KOJ100H60/3 N
Tray, KOJ100H60/3 N

Click on the photo to enlarge

Tray, KOJ100H60/3 N
Tray, KOJ100H60/3 N
Tray, KOJ100H60/3 N
Tray, KOJ100H60/3 N
Tray, KOJ100H60/3 N
Tray, KOJ100H60/3 N
Tray, KOJ100H60/3 N
Tray, KOJ100H60/3 N
Tray, KOJ100H60/3 N
Tray, KOJ100H60/3 N
Tray, KOJ100H60/3 N
BAKS

Tray, KOJ100H60/3 N 161610

local index:
TKM421BAKS
Catalog No:
161610
EAN code:
5900993034448
Price:
18,55 €
gross / pcs.
including VAT 23%
Availability:
up to 4 weeks (business days)
Delivery:
Large-size product
From 69,23 € (prepaid courier) Details
Quantity:
Goods at a promotional price can only be purchased in the quantity available in stock pcs.
Delivery methods:
Metody dostawy
details
Payment methods:
Metody płatności
details
Go to section:
Product description Technical data

Product description

The possibility of connecting the trays by sliding one into the other and assembly without connectors. For a large order, a cable tray with a length of 2 m. For assembly, use screw sets SGK M6x12 or SG M6x12

Print the product sheet Report an error

Technical data

  • Length [mm]
    3000
  • Material
    galvanized steel
  • Type
    KOJ100H60/3N
  • Compliance with standards
    PN-EN 103462011
  • Sheet thickness [mm]
    1
  • Width [mm]
    100
  • Weight 1m [kg]
    1.63

Other technical data

  • Height
    60 mm
  • Material thickness
    1 mm
  • Useful cross section
    5800 mm²
  • Side perforation
    yes
  • NATO-mounting holes
    no
  • Model szerokorozpiętościowy
    no
  • Material
    Steel
  • Material quality
    Other
  • Colour
    Other
  • Width
    100 mm
  • Length
    3000 mm
  • With cover
    no
  • Bottom perforation
    yes
  • Model
    Integrated connector
  • Suitable for circuit integrity
    no
  • Stainless steel, pickled
    no
  • Surface protection
    Hot-dip galvanized
  • Weight
    1.63 kg/m

Catalog cards, diagrams, certificates

BAKS-TM-BS-EN.pdf
Certyfikat-i-raport-VDE-ciągłość-elektryczna-koryt-drabin-i-ceowników-EN_DE.pdf
iso_pl.pdf
iso2_pl.pdf
Rekomendacja-Techniczna-ITB-RT1082_2012.pdf
SKM_C284e19060514120.pdf
Atest-Higieniczny.pdf
Deklaracja-Zgodności-CE-2020.10.16-standard.pdf
