BAKS

Tray, KCP600H80/3N 180860

local index:
TKM143BAKS
Catalog No:
180860
EAN code:
5900993035827
Price:
97,77 €
gross / pcs.
including VAT 23%
Availability:
up to 4 weeks (business days)
Delivery:
Large-size product
From 69,46 € (prepaid courier) Details
Quantity:
Goods at a promotional price can only be purchased in the quantity available in stock pcs.
Delivery methods:
Metody dostawy
details
Payment methods:
Metody płatności
details

Product description

Possibility of connecting KCL..., KCJ... and KCD... trays by sliding one into the other and assembly without connectors. KCP... trays can only be connected using connectors (no cut-out in the tray side). For a large order, a cable tray with a length of 6 m.
Screw sets SGK M6x12 or SG M6x12 should be used for assembly.

Technical data

  • Length [mm]
    3000
  • Material
    galvanized steel
  • Type
    KCP600H80/3N
  • Compliance with standards
    PN-EN 103462011
  • Sheet thickness [mm]
    1.5
  • Width [mm]
    600
  • Weight 1m [kg]
    7.86

Other technical data

  • Height
    80 mm
  • Material thickness
    1.5 mm
  • Useful cross section
    47800 mm²
  • Side perforation
    yes
  • NATO-mounting holes
    no
  • Model szerokorozpiętościowy
    no
  • Material
    Steel
  • Material quality
    Other
  • Colour
    Other
  • Width
    600 mm
  • Length
    3000 mm
  • With cover
    no
  • Bottom perforation
    yes
  • Model
    Without connector
  • Suitable for circuit integrity
    no
  • Stainless steel, pickled
    no
  • Surface protection
    Hot-dip galvanized
  • Weight
    7.39 kg/m
