142212
2
Channel KGL/KCL50H60 160424
local index:
TKM321BAKS
Catalog No:
160424
EAN code:
5900993183993
Large-size product
Price:
10,26 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Connectorless system. The option of connecting the trays by inserting one into the other and twisting. The use of fasteners is recommended only for heavy loads.
Material: Sendzimir galvanized steel PN-EN 10346:2015-09
On request:
L - varnishing in a standard RAL color
Additional information:
The possibility of connecting trays by sliding one in the second and assembly without fasteners. Use SGKM6x12 or SGM6x12 screws for assembly.
Technical data
-
weight [kg/100m]98
-
Sheet thickness [mm]0.7
-
Width [mm]50
-
Usable cross-section [mm²]2900
-
Length [mm]3000
-
Materialgalvanized steel
-
TypeKGL/KCL50H60/3
-
PKWIU25.11.23.0
Other technical data
-
Height60 mm
-
Material thickness0.7 mm
-
Useful cross section2900 mm²
-
Side perforationYes
-
NATO-mounting holesNo
-
Model szerokorozpiętościowyNo
-
MaterialSteel
-
Material qualityOther
-
ColourOther
-
Width50 mm
-
Length3000 mm
-
With coverNo
-
Bottom perforationYes
-
ModelIntegrated connector
-
Suitable for circuit integrityYes
-
Stainless steel, pickledNo
-
Surface protectionHot-dip galvanized
-
Weight0.98 kg/m
Manufacturer details
-
ManufacturerBAKS Kazimierz Sielski
-
Address05-480 KARCZEW JAGODNE 5
-
Phone number
-
E-mail
-
Tax identification number5320102041
-
GLN5909000679306
Files to download
