Channel KGL200H60/3 160316
local index:
TKM178BAKS
Catalog No:
160316
EAN code:
5900993108880
Large-size product
Price:
18,35 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Running a cable route.
The possibility of connecting trays by sliding
one into another and assembly without connectors.
For assembly, use screw sets
SGKM6x12 or SGM6x12.
The possibility of connecting trays by sliding
one into another and assembly without connectors.
For assembly, use screw sets
SGKM6x12 or SGM6x12.
Technical data
-
Length [mm]3000
-
Width [mm]200
-
Sheet thickness [mm]0.7
-
PKWIU25.11.23.0
Other technical data
-
Height60 mm
-
Material thickness0.7 mm
-
Useful cross section11800 mm²
-
Side perforationYes
-
NATO-mounting holesNo
-
Model szerokorozpiętościowyNo
-
MaterialSteel
-
Material qualityOther
-
ColourOther
-
Width200 mm
-
Length3000 mm
-
With coverNo
-
Bottom perforationYes
-
ModelIntegrated connector
-
Suitable for circuit integrityYes
-
Stainless steel, pickledNo
-
Surface protectionHot-dip galvanized
-
Weight1.68 kg/m
Manufacturer details
-
ManufacturerBAKS Kazimierz Sielski
-
Address05-480 KARCZEW JAGODNE 5
-
Phone number
-
E-mail
-
Tax identification number5320102041
-
GLN5909000679306
