Channel KCJ150H50/3 N 151015

local index:
TKM256BAKS
Catalog No:
151015
EAN code:
5900993032000
Manufacturer: BAKS
Sheet thickness [mm]: 1
Width [mm]: 150
Large-size product
Price:
21,92 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 4 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Print

Product description

Running a cable route.
The possibility of connecting the trays by sliding
one into the other and assembly without connectors.
Trays with a length of 2 m for large orders.
For assembly, use screw sets
SGK M6x10 or SG M6x10

Technical data

  • Sheet thickness [mm]
    1
  • PKWIU
    25.11.23.0
  • Width [mm]
    150

Other technical data

  • Height
    50 mm
  • Material thickness
    1 mm
  • Useful cross section
    7300 mm²
  • Side perforation
    yes
  • NATO-mounting holes
    no
  • Model szerokorozpiętościowy
    no
  • Material
    Steel
  • Material quality
    Other
  • Colour
    Other
  • Width
    150 mm
  • Length
    3000 mm
  • With cover
    no
  • Bottom perforation
    yes
  • Model
    Integrated connector
  • Suitable for circuit integrity
    no
  • Stainless steel, pickled
    no
  • Surface protection
    Hot-dip galvanized
  • Weight
    1.7 kg/m
