Channel KBR H42 KBR100H42/3 141610
local index:
TKM698BAKS
Catalog No:
141610
EAN code:
5900993030785
Large-size product
Price:
9,14 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Connectorless system. The option of connecting the trays by inserting one into the other and twisting. The use of fasteners is recommended only for heavy loads.
Material
< p>Sendzimir galvanized steel PN-EN 10346:2015-09On request:
F - hot-dip galvanized steel
PN-EN ISO 1461:2011 only for orders:
KBJ... above 300 m
E - stainless steel PN-EN 10088
L - painting in standard RAL color
Additional information
The ability to connect the trays by sliding one into the other
and assembly without connectors ;In. Screws SGKM6x12
or SGM6x12 should be used for assembly.
Technical data
-
Length [mm]3000
-
Materialgalvanized steel
-
TypeKBR100H42/3
-
PKWIU25.11.23.0
-
Sheet thickness [mm]0.7
-
Width [mm]100
-
Compliance with standardsPN-EN 103462011
Other technical data
-
Height42 mm
-
Material thickness0.5 mm
-
Useful cross section4000 mm²
-
Side perforationNo
-
NATO-mounting holesNo
-
Model szerokorozpiętościowyNo
-
MaterialSteel
-
Material qualityOther
-
ColourOther
-
Width100 mm
-
Length3000 mm
-
With coverNo
-
Bottom perforationNo
-
ModelIntegrated connector
-
Suitable for circuit integrityNo
-
Stainless steel, pickledNo
-
Surface protectionHot-dip galvanized
-
Weight0.8 kg/m
Manufacturer details
-
ManufacturerBAKS Kazimierz Sielski
-
Address05-480 KARCZEW JAGODNE 5
-
Phone number
-
E-mail
-
Tax identification number5320102041
-
GLN5909000679306
