Channel, KBJ600H60/3 161660
local index:
TKM406BAKS
Catalog No:
161660
EAN code:
5900993034981
Large-size product
Price:
59,95 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Possibility of connecting KBL..., KBJ... and KBD... trays by inserting one into the other and assembly without connectors. KBP... trays can only be connected using connectors (no cut-out in the tray side).
Screw sets SGK M6x12 or SG M6x12 should be used for assembly.
Screw sets SGK M6x12 or SG M6x12 should be used for assembly.
Technical data
-
Length [mm]3000
-
Materialgalvanized steel
-
TypeKBJ600H60/3
-
Compliance with standardsPN-EN 103462011
-
Sheet thickness [mm]1
-
Width [mm]600
-
Weight 1m [kg]6
-
PKWIU25.11.23.0
Other technical data
-
Height60 mm
-
Material thickness1 mm
-
Useful cross section35800 mm²
-
Side perforationNo
-
NATO-mounting holesNo
-
Model szerokorozpiętościowyNo
-
MaterialSteel
-
Material qualityOther
-
ColourOther
-
Width600 mm
-
Length3000 mm
-
With coverNo
-
Bottom perforationNo
-
ModelIntegrated connector
-
Suitable for circuit integrityNo
-
Stainless steel, pickledNo
-
Surface protectionHot-dip galvanized
-
Weight5.63 kg/m
Manufacturer details
-
ManufacturerBAKS Kazimierz Sielski
-
Address05-480 KARCZEW JAGODNE 5
-
Phone number
-
E-mail
-
Tax identification number5320102041
-
GLN5909000679306
