The most important functions: the design of the inverter based on a powerful 32-bit DSP processor ensures fast and effective implementation of advanced asynchronous control algorithms, the ability to work in speed control mode.
Technical data
Power [kW]
7.5
Maximum current [kA]
7.5
Output current [A]
16
Package width [mm]
160
Output current [A]
16
Rated voltage [V]
400
Input Current [A]
20
Package height [mm]
200
Package weight [kg]
2
PKWIU
27.11.50.0
Other technical data
Mains frequency
50 Hz
Number of phases output
3
Max. output voltage
400 V
Max. output at quadratic load at rated output voltage
7.5 kW
Relative symmetric net frequency tolerance
10 %
With control element
Yes
Application in domestic- and commercial area permitted
Yes
Supporting protocol for PROFIBUS
No
Supporting protocol for INTERBUS
No
Supporting protocol for KNX
No
Supporting protocol for Data-Highway
No
Supporting protocol for SUCONET
No
Supporting protocol for PROFINET IO
No
Supporting protocol for SERCOS
No
Supporting protocol for EtherNet/IP
No
Supporting protocol for DeviceNet Safety
No
Supporting protocol for PROFIsafe
No
Supporting protocol for other bus systems
No
Number of interfaces PROFINET
0
Number of HW-interfaces RS-422
0
Number of HW-interfaces serial TTY
0
Number of HW-interfaces parallel
0
With optical interface
No
4-quadrant operation possible
No
Degree of protection (IP)
IP20
Number of phases input
3
Max. output frequency
300 Hz
Nominal output current I2N
17 A
Max. output at linear load at rated output voltage
7.5 kW
Relative symmetric net voltage tolerance
10 %
Application in industrial area permitted
Yes
Supporting protocol for TCP/IP
No
Supporting protocol for CAN
No
Supporting protocol for ASI
No
Supporting protocol for Modbus
Yes
Supporting protocol for DeviceNet
No
Supporting protocol for LON
No
Supporting protocol for PROFINET CBA
No
Supporting protocol for Foundation Fieldbus
No
Supporting protocol for AS-Interface Safety at Work
