The most important functions: the design of the inverter based on a powerful 32-bit DSP processor ensures fast and effective implementation of advanced asynchronous control algorithms, the ability to work in speed control mode.
Technical data
Power [kW]
4
Maximum current [kA]
4
Output current [A]
16
Package width [mm]
160
Output current [A]
16
Rated voltage [V]
230
Input Current [A]
36
Package height [mm]
200
Package weight [kg]
2
PKWIU
27.11.50.0
Other technical data
Mains voltage
230 ... 230 V
Number of phases input
1
Max. output frequency
800 Hz
Max. output at linear load at rated output voltage
4 kW
Relative symmetric net voltage tolerance
15 %
Application in industrial area permitted
Yes
Supporting protocol for TCP/IP
No
Supporting protocol for CAN
No
Supporting protocol for ASI
No
Supporting protocol for Modbus
Yes
Supporting protocol for DeviceNet
No
Supporting protocol for LON
No
Supporting protocol for PROFINET CBA
No
Supporting protocol for Foundation Fieldbus
No
Supporting protocol for AS-Interface Safety at Work
No
Supporting protocol for INTERBUS-Safety
No
Supporting protocol for SafetyBUS p
No
Number of HW-interfaces industrial Ethernet
0
Number of HW-interfaces RS-232
0
Number of HW-interfaces RS-485
1
Number of HW-interfaces USB
0
Number of HW-interfaces other
0
Integrated breaking resistance
No
Type of converter
U converter
Height
220 mm
Depth
185.5 mm
Mains frequency
50/60 Hz
Number of phases output
3
Max. output at quadratic load at rated output voltage
4 kW
Relative symmetric net frequency tolerance
5 %
With control element
Yes
Application in domestic- and commercial area permitted
