PIR motion sensor IP40 1Z 10A 230V AC 1-500lx 180° 9m 186182300300

Name: PIR motion sensor IP40 1Z 10A 230V AC 1-500lx 180° 9m
Brand: FINDER
SKU: APK018FIND
Price: 852.09 PLN
Availability: BackOrder

Index local:

APK018FIND

Numéro de catalogue:

186182300300

Code EAN:

8012823376769

PIR motion sensor IP40 1Z 10A 230V AC 1-500lx 180° 9m

Cliquer sur la photo pour l'agrandir

Producteur: FINDER

Depth [mm]: 64.2

Detection angle [°]: 180

Contact material: AgSnO2

Voir la description complète

Prix:

852,09 zł

gross / pcs.

(y compris la TVA 23%)

En rupture de stock

Ajouter à la demande de devis

Imprimer

Renseignez-vous sur le produit

Description du produit Données techniques Détails du fabricant

Description du produit

Motion sensor with push-in terminals for mounting inside objects, with contact separated from the power circuit

Features:

Long detection range up to 120 m2
Modern design
Fast installation thanks to push-in terminals
1 NO contact 10 A with switch-on zero
Mounting to a 60 mm box or a 502 box
Double clamps for easy connection of sensors

Données techniques

Depth [mm]

64.2
Contact material

AgSnO2
Installation

Flush-mounted
Rated voltage [V]

230
Power consumption [VA]

1.5
Rated current [A]

10
Family

18
Width [mm]

88
Rated inrush current [A]

20
Maximum detection distance [m]

9
Rated AC switching voltage [V]

400
Rated switching power for AC15 (230V AC) [VA]

450
Sensitivity setting range [lx]

1-500

Detection angle [°]

180
Fixing

Push-in terminals
AC coil voltage [V]

110-230
Overvoltage resistance [kV]

1
Power consumption [W]

1
Contact type

Potential-free
Level of security

IP40
Height [mm]

88
Number of contacts

1Z
Type of coil voltage

AC
Rated switching power for AC1 [VA]

2500
Electrical durability AC1 [number of cycles]

100000
Switching time range [s-min]

12-35

Autres données techniques

Model

Movement sensor
HVAC-control

Yes
Animal zone

Yes
Networkable

Yes
Staircase light controller

Yes
Max. reach sideways

9 m
Diameter reach on floor

18 m
Remote operation

Yes
Response value luminosity adjustable

Yes
Teach-function for response value luminosity

Yes
Mounting method

Surface mounted
Material quality

Thermoplastic
Surface protection

Untreated
Colour

White
Degree of protection (IP)

IP40
Nominal voltage

230 V
Max. duty cycle

35 min
Response value luminosity

1 ... 500 lx
Temperature

-10 ... 50 °C
Substation input

Yes
Frequency

50 ... 60 Hz

Constant light control

Yes
Forced switch off

Yes
Creep-under protection

Yes
Optimum mounting height

1.1 m
Bridging switch

Yes
Max. reach frontally

9 m
Suitable for wireless transmission

Yes
Response value sensitivity adjustable

Yes
With signal unit

Yes
Dim function with dimmer basic element

Yes
Material

Plastic
Halogen free

Yes
Surface finishing

Matt
Transparent

Yes
Voltage type

AC
Min. switch-on time

12 s
Detection angle horizontal

180 ... 180 °
Max. switching power

1000 W
Max. starting current

100 A
Control current

7 mA
With alarm function

Yes
