IP20 motion sensor black DR-09B

Lokaler Index:
APK022FIFQ
Katalognummer:
DR-09B
EAN-Code:
5902431674872
Hersteller: F&F
Length [mm]: 102
Detection angle [°]: 360
Color: Black
Preis:
23,39 €
gross / stk.
(inklusive MwSt 23%)
Lieferung in 3h
Zugänglich 36 stk.
Abholung in 1 Stunde
Menge stk.
(mehrere:
1
)
Zur Zwischenablage hinzufügen
Drucken

Produktbeschreibung

Infrared motion sensorfor use in narrow corridors

With the function ofpresence sensor

Motion sensorallows forautomatic, temporary switching on of the lightin the event of a person or other object appearing in such places , such as: corridors, yards, approaches and driveways, garages, etc.
Motion sensorcan work indoors and outdoors. Outside only  in places where the sensor housing and its electrical connection points are not exposed to direct rain or snow or splashing with water or other liquid.

The infrared motion sensorworks by detecting movement of heat sources that are within its area of operation. Important elements affecting the detection efficiency are:

  • the amount of heat emitted by the moving object and the ambient temperature,

  • the size of the moving object ,

  • direction and speed of movement.

Efficiency of the infrared motion sensor  will be the smallest when:

  • the temperature of the moving object is close to the ambient temperature (e.g. a sunny room, a radiator in the detection field, etc.),

  • < li>

    the object moves at a low speed directly towards themotion sensor,

  • the size of the moving object will be small compared to area of the detection zone.

Examples of situations that may lead to incorrect operation of the infrared motion sensor:

    < light sources located in the sensor's detection field. Turning the light on or off causes a large and quick change in the temperature of the bulb, which can be interpreted by theinfrared motion sensor as a moving object.

Technische Daten

  • Length [mm]
    102
  • Color
    Black
  • Rated voltage [V]
    230
  • Rated current [A]
    10
  • Level of security
    IP20
  • Working temperature [°C]
    from -20 to +40
  • Power consumption in operating mode [W]
    0.45
  • PKWIU
    27.12.24.0
  • Detection angle [°]
    360
  • Installation
    Surface-mounted
  • Power consumption in standby mode [W]
    0.1
  • Twilight sensitivity threshold [lx]
    3-2000
  • Width [mm]
    102
  • Height [mm]
    55
  • Maximum detection distance [m]
    10

Weitere technische Daten

  • Model
    Movement sensor
  • Constant light control
    No
  • Forced switch off
    Yes
  • Creep-under protection
    No
  • Scan angle
    360 °
  • Staircase light controller
    Yes
  • Max. reach sideways
    8 m
  • Diameter reach on floor
    16 m
  • Remote operation
    No
  • Response value luminosity adjustable
    Yes
  • Teach-function for response value luminosity
    No
  • Suitable for wall mounting
    No
  • Mounting method
    Surface mounted
  • Material quality
    Thermoplastic
  • Surface finishing
    Matt
  • Transparent
    No
  • Voltage type
    AC
  • Nominal voltage
    230 V
  • Max. duty cycle
    13 min
  • Detection angle horizontal
    360 ... 360 °
  • Max. switching power
    800 W
  • Max. starting current
    10 A
  • With alarm function
    No
  • Height
    102 mm
  • Diameter
    115 mm
  • Sensor type
    Passive infrared
  • HVAC-control
    No
  • Animal zone
    No
  • Networkable
    No
  • Optimum mounting height
    2.8 m
  • Bridging switch
    No
  • Max. reach frontally
    8 m
  • Suitable for wireless transmission
    No
  • Response value sensitivity adjustable
    Yes
  • With signal unit
    No
  • Suitable for ceiling mounting
    Yes
  • Dim function with dimmer basic element
    No
  • Material
    Plastic
  • Halogen free
    Yes
  • Colour
    Black
  • Degree of protection (IP)
    IP20
  • Frequency
    50 ... 50 Hz
  • Min. switch-on time
    10 s
  • Switching-on delay
    1 s
  • Response value luminosity
    3 ... 2000 lx
  • Temperature
    -25 ... 50 °C
  • Substation input
    No
  • Width
    102 mm
  • Depth
    55 mm

Hersteller-Details

  • Hersteller
    F&F Filipowski S.K.
  • Adresse
    95-200 Pabianice Konstantynowska 79/81 Polska

Großpackungen

Eine Art Paket Sztuka
Menge 1 stk.
Breite (m) 0,110
Länge (m) 0,110
Tiefe (m) 0,065
