Flush-mounted motion sensor, 2 or 3 wires, 160 degrees 500W white OR-CR-220

local index:
APK013ORNO
Catalog No:
OR-CR-220
EAN code:
5901752483026
Manufacturer: ORNO POLSKA
angle [°]: 160
Color: White
Material: Plastic
Price:
12,21 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

A device dedicated to the automatic control of lighting or virtually any other electrical device. The sensor can operate in both 3-wire and 2-wire installations.
The device is characterized by simple assembly, it can be installed in a 60mm wall box, e.g. /li>
  • possibility to adjust the range of motion detection (SENS)
  • function to adjust the level of light intensity at which the relay is activated (LUX)
  • the device can work with LED lighting< /li>
  • housing made of durable plastic
  • lighting time min: 10 sec.±3 sec. max: 7 min.±2 min.
  • Technical data

    • angle [°]
      160
    • Material
      Plastic
    • Maximum power [W]
      500
    • Light intensity [lux]
      <3-2000
    • Working temperature [°C]
      -20 - +40
    • Accurate color
      White
    • Color
      White
    • Power [W]
      500
    • Installation
      Flush-mounted
    • Level of security
      IP20
    • Sensor range [m]
      9
    • PKWIU
      27.33.11.0
