Surge arrester SPCT2-460/3 167610

Indice locale:
AOG001MOEL
Numero di catalogo:
167610
Codice EAN:
4015081641000
Produttore: EATON
Level of security: IP20
Prezzo:
591,63 zł
gross / pezzi
(inclusa IVA 23%)
fino a 2 settimane
Su ordinazione
Quantità pezzi
(multiplo:
1
)
Aggiungi alla richiesta di preventivo
Aggiungi agli appunti
Stampa

Descrizione del prodotto

Surge arrester, SPCT2-460/3

Dati tecnici

  • Level of security
    IP20
  • PKWIU
    25.11.23.0

Altri dati tecnici

  • System configuration DC
    No
  • System configuration TN
    Yes
  • System configuration TN-C-S
    No
  • System configuration TT
    No
  • Number of conductors (without earthing)
    3
  • Max. discharge surge current (8/20)
    40 kA
  • Nominal voltage DC
    0 V
  • Max. continuous voltage DC
    0 V
  • Voltage protection level
    2.2 kV
  • Voltage protection level N-PE
    0 kV
  • Max. overcurrent protection device, series connection (fuse)
    125 A
  • Integrated short-circuit protection
    No
  • Integrated backup fuse
    No
  • Mounting method
    DIN rail (top hat rail) 35 mm
  • Max. conductor cross section solid (solid, stranded)
    25 mm²
  • With remote signalling contact
    No
  • Category type 2
    Yes
  • System configuration IT
    Yes
  • System configuration TN-C
    Yes
  • System configuration TN-S
    Yes
  • System configuration other
    Yes
  • Nominal discharge surge current (8/20)
    20 kA
  • Nominal voltage AC
    460 V
  • Max. continuous voltage AC
    460 V
  • Max. PV-voltage
    0 V
  • Voltage protection level L-N
    0 kV
  • Max. overcurrent protection device, parallel connection (fuse)
    0 A
  • Short-circuit breaking capacity (Isccr)
    0 kA
  • Integrated short-circuit protection selective to fuse gG
    0 A
  • Leakage-current free
    No
  • Construction size
    3 modular spacing
  • Max. conductor cross section flexible (fine-strand)
    35 mm²
  • Signalling at the device
    Optical
  • Degree of protection (IP)
    IP20

Dettagli del produttore

  • Produttore
    Eaton Electric Sp. z o.o.
  • Indirizzo
    80-299 Gdańsk Galaktyczna 30 Polska

Imballaggio sfuso

Una specie di pacchetto Skrzynia Karton
Quantità 1 pezzi 40 pezzi
Peso (kg) 0,560 13,959
Volume (m3) 0,000 0,016
Larghezza (m) 0,055 0,180
Lunghezza (m) 0,086 0,385
Profondità (m) 0,075 0,230
