Surge arrester cartridge SPCT2-280 167592
local index:
AOC019MOEL
Catalog No:
167592
EAN code:
4015081640843
Manufacturer:
EATON
Pieces in the package: 2
Price:
40,17 €
gross / pkg.
(including VAT 23%)
20,09 € gross/pcs.
Delivery in 3h
Pickup in 1h
Quantity pkg.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Surge arrester insert, SPCT2-280
Technical data
-
Pieces in the package2
Other technical data
-
System configuration DCNo
-
System configuration TNYes
-
System configuration TN-C-SNo
-
System configuration TTNo
-
Number of conductors (without earthing)0
-
Max. discharge surge current (8/20)40 kA
-
Nominal voltage DC0 V
-
Max. continuous voltage DC0 V
-
Voltage protection level1.4 kV
-
Voltage protection level N-PE0 kV
-
Max. overcurrent protection device, series connection (fuse)125 A
-
Integrated short-circuit protectionNo
-
Integrated backup fuseNo
-
Mounting methodOn basic element
-
Max. conductor cross section solid (solid, stranded)25 mm²
-
With remote signalling contactNo
-
Category type 2Yes
-
System configuration ITNo
-
System configuration TN-CNo
-
System configuration TN-SNo
-
System configuration otherYes
-
Nominal discharge surge current (8/20)20 kA
-
Nominal voltage AC280 V
-
Max. continuous voltage AC280 V
-
Max. PV-voltage0 V
-
Voltage protection level L-N0 kV
-
Max. overcurrent protection device, parallel connection (fuse)0 A
-
Short-circuit breaking capacity (Isccr)0 kA
-
Integrated short-circuit protection selective to fuse gG0 A
-
Leakage-current freeNo
-
Construction size1 modular spacing
-
Max. conductor cross section flexible (fine-strand)0 mm²
-
Signalling at the deviceOptical
-
Degree of protection (IP)IP20
Manufacturer details
-
ManufacturerEATON Electric Sp. z o.o.
-
Address80-299 Gdańsk ul. Galaktyczna 30
-
Tax identification number5841022327
Bulk packaging
| A kind of package | Karton | Karton | |
| Quantity | 1 pkg. | 1 pkg. | 60 pkg. |
| Weight (kg) | 0,044 | 0,114 | 6,319 |
| Volume (m3) | 0,000 | 0,000 | 0,016 |
| Width (m) | 0,018 | 0,037 | 0,180 |
| Length (m) | 0,047 | 0,086 | 0,385 |
| Depth (m) | 0,054 | 0,075 | 0,230 |
