HQI T D I 2000W E40 discharge bulb 4008321527011

local index:
CCM005LEDV
Catalog No:
4008321527011
EAN code:
4008321527011
Manufacturer: LEDVANCE
Light color [K]: 4800-6500 (cool)
Length [mm]: 430
Bubble shape: Cylindrical, one-sided shank
Price:
233,87 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to a week (working days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Product benefits:
Power up to 2000W
High luminous efficiency
E40 screw base for easy handling
Long durability
UV values well below the maximum permitted thresholds in accordance with PN-EN EN 61167 thanks to UV filter

Area of application:
Industrial plants and workshops
Sports halls and multi-purpose halls
Industrial installations
Airports
Docks and Ports
Marshalling Yards, Container Terminals
Approved for use in enclosed luminaires only
Outdoor Applications - only in suitable luminaires

Product Features:
Quartz Technology POWERSTAR
Light colors: neutral white (cool white) (N), daylight (daylight) (D)
Working position: p30

Technical data

  • Light color [K]
    4800-6500 (cool)
  • Bubble shape
    Cylindrical, one-sided shank
  • Power [W]
    2000
  • Rated current [A]
    10.1
  • Diameter [mm]
    100
  • Handle
    E40
  • Package weight [kg]
    0.74
  • Color Temperature [K]
    7450
  • Length [mm]
    430
  • LED
    NO
  • Rated voltage [V]
    230
  • luminous flux [lm]
    180000
  • Durability [h]
    9000
  • Package width [mm]
    130
  • Package length [mm]
    465
  • PKWIU
    27.40.15

Other technical data

  • Lamp power
    2000.00 W
  • Luminous flux
    180000 lm
  • UV protection
    Yes
  • Colour temperature
    7450 K
  • Lamp efficacy
    90 lm/W
  • Material discharge tube
    Quartz
  • Diameter
    106.0 mm
  • External ignitor required
    No
  • Closed luminaire required
    Yes
  • Colour of light
    860
  • Lamp designation
    Other
  • Weighted energy consumption in 1000 hours
    2332 kWh
  • Lamp voltage
    230 ... 230 V
  • Socket
    E40
  • Colour rendering index CRI
    80-89
  • Colour of light according to EN 12464-1
    Daylight white >5300 K
  • Lamp shape
    Tube, single-ended
  • Burning position
    P30
  • Total length
    430.0 mm
  • External ballast required
    Yes
  • Sun tanning lamp
    No
  • Model
    Clear
  • Energy efficiency class
    A
  • Average nominal lifespan
    9000 h

Manufacturer details

  • Manufacturer
    LEDVANCE GmbH
  • Address
    85748 Garching Parkring 29-33 Niemcy

Bulk packaging

A kind of package Zwój Karton
Quantity 1 pcs. 4 pcs.
Weight (kg) 0,740 3,583
Volume (m3) 0,008 0,039
Width (m) 0,130 0,270
Length (m) 0,470 0,280
Depth (m) 0,130 0,530
