FLOODLIGHT 10 LED floodlight 230V 10W 1100lm IP65 n/t NW 100st white 4058075097421

Lokaler Index:
OZC037LEDV
Katalognummer:
4058075097421
EAN-Code:
4058075097421
Hersteller: LEDVANCE
Light color [K]: 3500-4800 (natural)
Color Rendering Index [CRI]: >80
Length [mm]: 125
Preis:
15,55 €
gross / stk.
(inklusive MwSt 23%)
Lieferung in 3h
Nicht auf Lager
Abholung in 1 Stunde
Menge stk.
(mehrere:
1
)
Drucken

Produktbeschreibung

LED floodlightwith 10W power and symmetrical light distribution, from the FLOODLIGHT series.

Benefits of using the product:

  • Up to 90% energy savings (compared to floodlights with halogen lamps).
  • Optimized weight and dimensions thanks to compact design,
< p> Area of application:

  • Replacement of floodlights for halogen bulbs,
  • Parking lots and underground passages,
  • Garages,< /li>
  • Public areas,
  • Construction sites.

Product features:

  • Ambient temperature during operation: -20…+50°C,
  • Connection cable 1 m long, wiring required.

Technische Daten

  • Light color [K]
    3500-4800 (natural)
  • Length [mm]
    125
  • Protection class
    AND
  • Material
    Plastic Glass
  • Installation
    Surface-mounted
  • Family
    FLOODLIGHT
  • Level of security
    IP65
  • Width [mm]
    115
  • Height [mm]
    39
  • Color Temperature [K]
    4000
  • Color Rendering Index [CRI]
    >80
  • beam angle [°]
    100
  • Color
    White
  • Power [W]
    10
  • Rated voltage [V]
    230
  • Luminous efficiency [lm/W]
    110
  • luminous flux [lm]
    1100
  • Durability [h]
    50000
  • Degree of mechanical protection
    IK07
  • PKWIU
    27.40.25

Weitere technische Daten

  • Suitable for surface mounting
    Yes
  • Suitable for wall mounting
    Yes
  • Suitable for ceiling mounting
    No
  • With movement sensor
    No
  • Lamp type
    LED not exchangeable
  • Housing material
    Plastic
  • Housing colour
    White
  • Voltage type
    AC
  • Prąd znamionowy LED przy zasilaniu prądem stałym
    48 ... 48 mA
  • With control gear
    Yes
  • Dimming 1-10 V
    No
  • Dimming DMX
    No
  • Dimming potentiometer (integrated)
    No
  • Dimming LineSwitch
    No
  • Dimming mains voltage modulation
    No
  • Dimming phase cut-on
    No
  • Dimming RF
    No
  • Dimming Touch and Dim
    No
  • Dimming with push-button
    No
  • Reflector
    None
  • Light sharing
    Symmetric
  • Light outlet
    Direct
  • Total harmonic distortion
    19
  • Rated life time L70/B50 at 25 °C
    50000 h
  • Żywotność znamionowa L80/B50 przy 25 °C
    30000 h
  • Żywotność znamionowa L90/B50 przy 25 °C
    15000 h
  • Impact strength
    IK07
  • Rated ambient temperature according to IEC 62722-2-1
    -20 ... +50 °C
  • Colour of light
    White
  • Colour rendering index CRI
    80-89
  • Rated luminous flux according to IEC 62722-2-1
    1100 lm
  • Width
    115.0 mm
  • Length
    125.0 mm
  • Number of poles
    2
  • Luminaire efficacy
    110 lm/W
  • Covering of the luminaire with thermally insulating material possible
    No
  • Photobiological safety according to EN 62471
    RG0
  • Suitable for built-in mounting
    No
  • Suitable for suspended mounting
    No
  • Adjustability
    Swivelling
  • With light sensor
    No
  • With light source
    Yes
  • Surface protection
    Untreated
  • Material cover
    Glass opal
  • Nominal voltage
    220 ... 240 V
  • Type of control gear
    Electronic ballast
  • Dimming 0-10 V
    No
  • Dimming DALI
    No
  • Dimming DSI
    No
  • Ściemniacz GPRS
    No
  • Dimming manufacturer's proprietary system
    No
  • Dimming phase cut-off
    No
  • Dimming programmable
    No
  • Dimming Sine Wave Reduction
    No
  • Dimming Zigbee
    No
  • No dim function
    Yes
  • Light distributor
    Reflector
  • Beam angle
    Open beam/diffuse
  • Klasa efektywności energetycznej zamontowanego źródła światła
    A++, A+, A (LED)
  • Żywotność znamionowa L70/B10 przy 25 °C
    50000 h
  • Rated life time L80/B10 at 25 °C
    30000 h
  • Żywotność znamionowa L90/B10 przy 25°C
    15000 h
  • Degree of protection (IP)
    IP65
  • Protection class
    I
  • Max. system power
    10 W
  • Colour temperature
    4000 ... 4000 K
  • Luminous flux
    1100 ... 1100 lm
  • Lamp efficacy
    110 lm/W
  • Height/depth
    39.0 mm
  • Type of wiring
    Ending
  • Connection type
    Other
  • Suitable for workplace according to EN 12464-1
    No
  • Filament test according to IEC 60695-2-11
    650 °C - 30 s
  • Colour consistency (McAdam ellipse)
    SDCM5
