DL 220 LED EVO Office luminaire 230W 10W IP65 1350lm white p/t 519529

Index local:
OZG055LENA
Numéro de catalogue:
519529
Code EAN:
5905963519529
Producteur: LENA LIGHTING
Energy class: A+
Protection class: AND
Color: White
Prix:
259,41 zł
gross / pcs.
(y compris la TVA 23%)
jusqu'à 4 semaines
Sur commande
Quantité pcs.
(plusieurs:
1
)
Ajouter à la demande de devis
Ajouter au presse-papiers
Imprimer

Description du produit

The luminaire is intended for both indoor (offices, communication routes, utility rooms) and outdoor use. Due to the possibility of making it with a ballast adapted to cooperate with external lighting systems, it is especially recommended for class A office buildings. It provides good lighting of the surface and is conducive to work requiring high concentration of eyesight. Designed to be installed in any type of suspended ceiling.

Données techniques

  • Energy class
    A+
  • Color
    White
  • Power [W]
    10
  • Rated voltage [V]
    230
  • Luminous efficiency [lm/W]
    110
  • luminous flux [lm]
    1350
  • Dimensions (width x height) [mm]
    Ø220x68
  • Material type
    ABS
  • Lampshade type
    Submatic matte
  • cri (ra)
    >80
  • Protection class
    AND
  • Material
    ABS
  • Installation
    Flush-mounted
  • Family
    DL 220 LED EVO
  • Level of security
    IP65
  • Durability [h]
    50000
  • Dimensions (length x width x height) [mm]
    Ø220x68
  • Degree of mechanical protection
    IK08
  • Color Temperature [K]
    3000
  • Mounting dimensions [mm]
    Ø205

Autres données techniques

  • Suitable for wall mounting
    No
  • Suitable for ceiling mounting
    Yes
  • Suitable for surface mounting
    No
  • Lamp type
    LED exchangeable
  • Housing material
    Plastic
  • Material cover
    Plastic, opal
  • With control gear
    Yes
  • Dimming 1-10 V
    No
  • Dimming DMX
    No
  • Dimming potentiometer (integrated)
    No
  • Dimming LineSwitch
    No
  • Dimming mains voltage modulation
    No
  • Dimming phase cut-on
    No
  • Dimming RF
    No
  • Dimming Touch and Dim
    No
  • Dimming with push-button
    No
  • Rated life time L70/B50 at 25 °C
    50000 h
  • Impact strength
    IK08
  • Suitable for emergency lighting
    No
  • With light sensor
    No
  • Rated luminous flux according to IEC 62722-2-1
    1350 lm
  • Luminaire efficacy
    110 lm/W
  • Height/depth
    68 mm
  • Built-in diameter
    205 mm
  • Suitable for suspended mounting
    No
  • Suitable for built-in mounting
    Yes
  • Suitable for light line configuration
    No
  • With light source
    Yes
  • Housing colour
    White
  • Type of grid
    None
  • Dimming 0-10 V
    No
  • Dimming DALI
    No
  • Dimming DSI
    No
  • Ściemniacz GPRS
    No
  • Dimming manufacturer's proprietary system
    No
  • Dimming phase cut-off
    No
  • Dimming programmable
    No
  • Dimming Sine Wave Reduction
    No
  • Dimming Zigbee
    No
  • Ściemniacz zależny od statecznika
    No
  • Degree of protection (IP)
    IP65
  • Protection class
    I
  • With movement sensor
    No
  • Max. system power
    10 W
  • Colour temperature
    3000 ... 3000 K
  • Power factor
    0.92
  • Outer diameter
    220 mm

Détails du fabricant

  • Producteur
    Lena Lighting S.A
  • Adresse
    63-000 Środa Wielkopolska Kórnicka 52 Polska
