W.1 Module single speaker socket with cover IP55 grey 11963525

Indice locale:
MEG002BERK
Numero di catalogo:
11963525
Codice EAN:
4011334440925
Produttore: BERKER
Number of sockets: 1
Color: Gray
Shape: Square
Prezzo:
28,02 €
gross / pezzi
(inclusa IVA 23%)
Consegna in 3 ore
fino a 10 settimane (giorni lavorativi)
Raccolta in 1h
Quantità pezzi
(multiplo:
1
)
Aggiungi agli appunti
Stampa

Descrizione del prodotto

Speaker socket from the W.1 series, from the manufacturer Berker. The product part number is 11963525.



FEATURES

  • Single.< /li>
  • Color Light Grey.
  • Rating IP55.
  • With transparent cover.
  • With plug-in terminals (double-sided).
  • With 2-wire entry and cable or pipe entry.
  • Hinged cover, stainless steel, quick release pins for lock ZAMAK.



SERIES DESCRIPTION

Berker W.1 is a series of waterproof electrical installation equipment which ra is distinguished by its innovative design. The Speaker socket characterizes the features of this series.

Dati tecnici

  • Number of sockets
    1
  • Shape
    Square
  • Installation
    Recessed Surface-mounted
  • Type
    speaker
  • Level of security
    IP55
  • Surface finish
    matte
  • Accurate color
    light gray
  • Variant
    Pin-type plugs
  • PKWIU
    27.12.40.0
  • Color
    Gray
  • Material
    Plastic
  • Descriptive field
    Yes
  • Family
    W.1
  • Type
    Recessed Surface-mounted
  • Maximum conductor cross-section [mm²]
    2.5
  • Backlight
    NO
  • Exact material
    Thermoplastic

Altri dati tecnici

  • Assembly arrangement
    Basic element with full cover plate
  • With dust cover
    Yes
  • Imprintable label
    With indication plate
  • Material
    Plastic
  • Halogen free
    Yes
  • Surface finishing
    Matt
  • RAL-number (similar)
    7011
  • Type of fastening
    Mounting with screw
  • With strain relief
    No
  • Luster terminal
    No
  • Device width
    70 mm
  • Device depth
    51 mm
  • Utilization
    Loudspeaker connection
  • With hinged lid
    Yes
  • Mounting method
    Surface mounted
  • Material quality
    Thermoplastic
  • Surface protection
    Untreated
  • Colour
    Grey
  • Transparent
    No
  • With buses/couplings
    No
  • Shielded buses
    No
  • Suitable for degree of protection (IP)
    IP55
  • Device height
    70 mm
  • Min. depth of built-in installation box
    35 mm

Dettagli del produttore

Imballaggio sfuso

Una specie di pacchetto Karton Pakiet Paleta
Quantità 1 pezzi 1 pezzi 36 pezzi 1152 pezzi
Peso (kg) 0,054 0,070 3,068 118,169
Larghezza (m) 0,070 0,080 0,300 0,800
Lunghezza (m) 0,051 0,070 0,225 1,050
Profondità (m) 0,070 0,085 0,400 1,200
