Manufacturer: TEHALIT
Depth [mm]: 33
Number of keys: 1
Number of modules: 2
Price:
19,45 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 10 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Cross connector of the  systo series. The product part number is WS010.



FEATURES

  • Single button.
  • Type of contact: 2-way.
  • Type of connection: Quick Connect.



SERIES DESCRIPTION

systo is a series of electro-installation equipment that can be used in a ró various installations: floor boxes, columns or ducts. The Cross connector characterizes the features of this unique series.

Technical data

  • Depth [mm]
    33
  • Number of modules
    2
  • Shape
    Square
  • Rated voltage [V]
    230
  • Type
    Cross
  • Level of security
    IP31D
  • Type
    45x45
  • Degree of mechanical protection
    IK07
  • Backlight
    NO
  • Exact material
    PC
  • Number of keys
    1
  • Color
    White
  • Material
    Plastic
  • Rated current [A]
    10
  • Family
    SYSTEM
  • Width [mm]
    45
  • Height [mm]
    45
  • Surface finish
    matte
  • For the frame system
    Yes
  • PKWIU
    27.33.11.0

Other technical data

  • Wiring system
    Intermediate switch
  • Assembly arrangement
    Basic element with central cover plate
  • Push button switch
    No
  • Type of fastening
    Engage (snap)
  • Material
    Plastic
  • Surface protection
    Lacquered
  • Colour
    White
  • Label space/information surface
    No
  • Function lighting
    Other
  • Suitable for degree of protection (IP)
    IP31
  • Rated current
    10 A
  • Feedback-signal contact
    No
  • Device width
    45 mm
  • Device depth
    33 mm
  • Min. depth of built-in installation box
    40 mm
  • Method of operation
    Rocker/button
  • Number of modules (module system)
    2
  • Mounting method
    Flush-mounted
  • With mounting plate
    No
  • Material quality
    Thermoplastic
  • Surface finishing
    Matt
  • RAL-number (similar)
    9010
  • Illumination
    No
  • Type of lighting
    Other
  • Nominal voltage
    250 V
  • Switching current for fluorescent lamps
    10 AX
  • Connection type
    Push-in clamp
  • Device height
    45 mm
  • Built-in depth
    40 mm

Bulk packaging

A kind of package Karton Pakiet Paleta
Quantity 1 pcs. 1 pcs. 60 pcs. 1440 pcs.
Weight (kg) 0,054 0,055 3,857 115,568
Width (m) 0,045 0,067 0,321 0,800
Length (m) 0,045 0,064 0,221 1,034
Depth (m) 0,033 0,072 0,369 1,200
