SYSTEM M Mechanism of computer data socket 1xRJ45 cat. 6 UTP MTN4576-0001

local index:
MJI004MERT
Catalog number:
MTN4576-0001
EAN code:
3606480421242
Manufacturer: MERTEN
Category: 6
Shape: Square
Material: Plastic | Metal
Price:
118,79 zł
gross / pcs.
(including VAT 23%)
2 weeks
On request
Quantity pcs.
(multiplicity:
1
)
Add to inquiry
Add to clipboard
Print

Product description

Internet computer socket mechanism from the System Merten M series, from the manufacturer Merten. The product catalog number is  MTN4576-0001.



FEATURES

  • 1 x RJ45.
  • Category 6.
  • UTP.
  • With mounting frame.
  • Flush mounting.

Technical data

  • Category
    6
  • Material
    Plastic Metal
  • Installation
    Flush-mounted
  • Family
    SYSTEM M
  • Type
    Socket mechanism
  • Variant
    RJ45 (twisted pair)
  • Number of internet sockets
    1
  • Shape
    Square
  • Fixing
    Screws Pliers
  • Type
    Internet
  • Level of security
    IP20
  • Version
    UTP
  • For the frame system
    Yes NO
  • PKWIU
    27.33.13.0

Other technical data

  • Surface mounting
    Yes
  • Floor box/subfloor mounted
    Yes
  • Assembly arrangement
    Basic element with full cover plate
  • With buses/couplings
    Yes
  • Category
    6
  • Shielded buses
    Yes
  • Separate earthing connection
    No
  • Compatible with third-party covers
    Yes
  • Mounting method shielding connection
    Clip
  • With dust cover
    No
  • Mechanical coding
    Yes
  • Device width
    71 mm
  • Device depth
    35 mm
  • Duct installation
    Yes
  • Type of fastening
    Screwing
  • Type of connector
    RJ45 8(8)
  • Suitable for number of connectors
    1
  • Connection type
    Insulation displacement connector
  • Shielded housing
    Yes
  • With label space
    No
  • Separate strain relief
    No
  • Outlet direction
    Straight
  • Degree of protection (IP)
    IP20
  • Colour coding
    Yes
  • Device height
    71 mm

Manufacturer details

  • Manufacturer
    Schneider Electric Polska
  • Address
    02-673 Warszawa Konstruktorska 12 Polska
