Socket (module), 230V, metallic stainless steel BMG1Z.01/21

local index:
MEE132KONT
Catalog No:
BMG1Z.01/21
EAN code:
5902787814977
Manufacturer: KONTAKT-SIMON
Halogen free: Yes
Depth [mm]: 40.5
Number of sockets: 1
Price:
6,17 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Socket from the Simon Basic series, from the manufacturer Contact Simon. The product part number is BMG1Z.01/21.



FEATURES

  • Single.
  • Ungrounded.
  • Screw terminals.
  • To be fitted with frame.< /li>
  • Current paths shutters.
  • Color inox, metallic.
  • Rated current 16A.
  • Rated voltage 230V.
  • Ingress protection IP20.
  • Mounting flush.
  • Dimensions: 75 x 75 mm (height x width).
  • Made of PC.< /li>



SERIES DESCRIPTION

Functionality and classic look are the hallmarks of the Simon Basic series, which will in every space. The color palette makes it possible to subtly integrate switches and sockets into the design of an apartment, premises, living room or office.

Technical data

  • Halogen free
    Yes
  • Number of sockets
    1
  • Shape
    Square
  • Fixing
    claws Screws
  • Rated voltage [V]
    230
  • Type
    Electric
  • Level of security
    IP20
  • Type
    Flush-mounted
  • Height [mm]
    75
  • Surface finish
    matte
  • Backlight
    NO
  • Terminal type
    Threaded
  • Shutters of current paths
    Yes
  • For the frame system
    Yes
  • PKWIU
    27.33.13.0
  • Depth [mm]
    40.5
  • Color
    Silver
  • Material
    Plastic
  • Installation
    Flush-mounted
  • Rated current [A]
    16
  • Family
    SIMON BASIC
  • Width [mm]
    75
  • Ground
    Lack
  • Surface protection
    varnishing
  • Accurate color
    Metallized stainless steel
  • Mounting depth [mm]
    28
  • Standard
    European
  • On the DATA key
    NO
  • Exact material
    PC

Bulk packaging

A kind of package Paczka Karton
Quantity 1 pcs. 1 pcs. 10 pcs.
Weight (kg) 0,072 0,072 0,811
Width (m) 0,075 0,110 0,190
Length (m) 0,075 0,046 0,230
Depth (m) 0,041 0,160 0,100
