SIMON BASIC Triple switch with LED backlight 10A 250V beige BMW31L.01/12

local index:
MMW013KONT
Catalog No:
BMW31L.01/12
EAN code:
5902787859855
Manufacturer: KONTAKT-SIMON
Halogen free: Yes
Number of keys: 3
Color: Beige
Price:
11,94 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 4 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Triple connector from the Simon Basic series, from the manufacturer Contact Simon. The product part number is BMW31L.01/12.



FEATURES

  • 3x1-pole connector ( bistable).
  • With LED backlight (not replaceable).
  • Quick connectors.
  • Rocker switch.

 < /p>



SERIES DESCRIPTION

Simon Basic is a series of electrical equipment based on classic design and functionality. The triple connector has all the features of this unique series.

Technical data

  • Halogen free
    Yes
  • Color
    Beige
  • Material
    Plastic
  • Installation
    Flush-mounted
  • Rated current [A]
    10
  • Family
    SIMON BASIC
  • Width [mm]
    75
  • Height [mm]
    75
  • Surface finish
    Shiny
  • Terminal type
    Threadless
  • Exact material
    PC
  • Backlight color
    Blue
  • Number of keys
    3
  • Shape
    Square
  • Fixing
    claws Screws
  • Rated voltage [V]
    230
  • Type
    Multi-key
  • Level of security
    IP20
  • Type
    Flush-mounted
  • Surface protection
    Natural
  • Backlight
    Yes
  • For the frame system
    Yes
  • Backlight type
    LED
  • PKWIU
    27.33.11.0

Bulk packaging

A kind of package Paczka Karton
Quantity 1 pcs. 1 pcs. 10 pcs.
Weight (kg) 0,076 0,076 0,860
Width (m) 0,075 0,110 0,190
Length (m) 0,075 0,045 0,230
Depth (m) 0,041 0,160 0,100
