SIMON BASIC Triple button with LED backlight 10A 250V white BMP31L.01/11

local index:
MMZ131KONT
Catalog No:
BMP31L.01/11
EAN code:
5902787859701
Manufacturer: KONTAKT-SIMON
Halogen free: Yes
Number of keys: 3
Color: White
Price:
12,69 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 4 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Triple button with backlight,  Simon Basic series, from the manufacturer Contact Simon. Product catalog number it is BMP31L.01/11. In white.



FEATURES

  • Quick connectors.< /li>
  • 3x1-pole pushbutton (monostable)
  • LED backlight (not replaceable), blue.



SERIES DESCRIPTION

Functionality and classic look are the hallmarks of the Simon Basic series, which will work in any space. The color palette makes it possible to subtly integrate switches and sockets into the design of an apartment, premises, living room or office.

Technical data

  • Halogen free
    Yes
  • Color
    White
  • Material
    Plastic
  • Installation
    Flush-mounted
  • Rated current [A]
    10
  • Family
    SIMON BASIC
  • Width [mm]
    75
  • Version
    Confident
  • Surface protection
    Natural
  • Backlight
    Yes
  • Variant
    Ordinary
  • Exact material
    PC
  • Backlight color
    Blue
  • Number of keys
    3
  • Shape
    Square
  • Fixing
    claws Screws
  • Rated voltage [V]
    230
  • Type
    Short
  • Level of security
    IP20
  • Type
    Flush-mounted
  • Height [mm]
    75
  • Surface finish
    Shiny
  • Terminal type
    Threadless
  • For the frame system
    Yes
  • Backlight type
    LED
  • PKWIU
    27.33.11.0

Bulk packaging

A kind of package Paczka Karton
Quantity 1 pcs. 1 pcs. 10 pcs.
Weight (kg) 0,077 0,077 0,860
Width (m) 0,075 0,110 0,190
Length (m) 0,075 0,045 0,230
Depth (m) 0,041 0,160 0,100
