SIMON 54 Triple button with backlight (module) 10AX 250V quick connectors matt bronze metallized DP31L.01/46

local index:
MMZ226KONT
Catalog No:
DP31L.01/46
EAN code:
5902787857349
Manufacturer: KONTAKT-SIMON
Halogen free: Yes
Depth [mm]: 34
Number of keys: 3
Price:
16,36 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 4 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Triple button with backlight, series Simon 54, from the manufacturer Contact Simon. Product catalog number it's DP31L.01/46. In brown matt, metallic.



FEATURES

  • Quick connectors.
  • 3x1-pole pushbutton (monostable)
  • Built-in LED backlight (non-replaceable), blue.



SERIES DESCRIPTION

SIMON 54 is a modern line of electrical installation equipment based on new, reliable and easy-to-install mechanisms, distinguished by its noble form and rich colors.

Technical data

  • Halogen free
    Yes
  • Number of keys
    3
  • Shape
    Square
  • Fixing
    Screws
  • Rated voltage [V]
    230
  • Type
    Short
  • Level of security
    IP20
  • Type
    Flush-mounted
  • Height [mm]
    75
  • Surface finish
    matte
  • Backlight
    Yes
  • Terminal type
    Threadless
  • For the frame system
    Yes
  • Backlight type
    LED
  • PKWIU
    27.33.11.0
  • Depth [mm]
    34
  • Color
    Brown
  • Material
    Plastic
  • Installation
    Flush-mounted
  • Rated current [A]
    10
  • Family
    Simon 54
  • Width [mm]
    75
  • Version
    Confident
  • Surface protection
    varnishing
  • Accurate color
    Bronze mat
  • Mounting depth [mm]
    20
  • Variant
    Ordinary
  • Exact material
    PC
  • Backlight color
    Blue

Bulk packaging

A kind of package Paczka Karton
Quantity 1 pcs. 1 pcs. 10 pcs.
Weight (kg) 0,068 0,068 0,760
Width (m) 0,075 0,110 0,190
Length (m) 0,075 0,040 0,230
Depth (m) 0,034 0,160 0,100
