SIMON 54 Double shutter switch (module), 250V, quick connectors, anthracite DZW2.01/11

Índice local:
MMO078KONT
Número de catálogo:
DZW2.01/11
Fabricante: KONTAKT-SIMON
Halogen free: Yes
Depth [mm]: 41
Number of keys: 1
Precio:
15,58 €
gross / uds.
(IVA incluido 23%)
Entrega en 3h
Fuera de stock
Recogida en 1h
Cantidad uds.
(múltiple:
1
)
Añadir a solicitud de presupuesto
Imprimir

Descripción del producto

Louvre connector from the Simon 54 series, from the manufacturer Contact Simon. The product catalog number is DZW2.01/11.



FEATURES

  • Double.
  • Tri-position (1-0-2).
  • Quick connectors.
  • Comes with a decorative ring in the color of the module.
< p>

SERIES DESCRIPTION

Simon 54 is a series of modern installation accessories, distinguished by reliable and easy-to-install mechanisms and a variety of color. The shutter connector characterizes the features of this unique series.

Datos técnicos

  • Halogen free
    Yes
  • Number of keys
    1
  • Shape
    Square
  • Fixing
    claws Screws
  • Rated voltage [V]
    230
  • Type
    Shutter
  • Level of security
    IP20
  • Width [mm]
    75
  • Version
    Double
  • Surface protection
    Natural
  • Backlight
    NO
  • Terminal type
    Threadless
  • For the frame system
    Yes
  • Depth [mm]
    41
  • Color
    White
  • Material
    Plastic
  • Installation
    Flush-mounted
  • Rated current [A]
    10
  • Family
    Simon 54
  • Symbol
    Blinds
  • Type
    Flush-mounted
  • Height [mm]
    75
  • Surface finish
    Shiny
  • Mounting depth [mm]
    26
  • Variant
    Three-position
  • Exact material
    PC

Detalles del fabricante

  • Fabricante
    KONTAKT - SIMON SPÓŁKA AKCYJNA
  • Dirección
    43-500 UL. BESTWIŃSKA 21
  • NIF
    6520005366
