R-TV-DATA socket (module) metallic satin BMAD.01/29
local index:
MEA063KONT
Catalog No:
BMAD.01/29
EAN code:
5902787819033
Price:
24,16 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
R-TV-DATA antenna socket from the SIMON BASIC NEOS / STANDARD series.
Technical data
-
Halogen freeYes
-
Number of sockets3
-
ShapeSquare
-
Fixingclaws Screws
-
OverprintYes
-
FamilySIMON BASIC
-
Width [mm]75
-
TypeFlush-mounted
-
Height [mm]75
-
Frequency Range [MHz]5-862
-
Accurate colorSatin metallic
-
Mounting depth [mm]29
-
VariantR TV DATE
-
For the frame systemYes
-
PKWIU27.33.13.0
-
Depth [mm]41
-
ColorSilver
-
MaterialPlastic
-
InstallationFlush-mounted
-
TypeAntenna
-
Level of securityIP20
-
Attenuation [dB]Connections for 860 MHz: 10
-
VersionFinal
-
Surface protectionvarnishing
-
Surface finishmatte
-
BacklightNO
-
Terminal typeThreaded
-
F-type inputNO
-
Exact materialPC
Other technical data
-
ModelEnd socket
-
Number of outlets3
-
Frequency5 ... 862 MHz
-
Tap loss at 860 MHz10 dB
-
Suitable for remote power supplyNo
Bulk packaging
| A kind of package | Paczka | Karton | |
| Quantity | 1 pcs. | 1 pcs. | 10 pcs. |
| Weight (kg) | 0,120 | 0,120 | 1,291 |
| Width (m) | 0,075 | 0,110 | 0,190 |
| Length (m) | 0,075 | 0,046 | 0,230 |
| Depth (m) | 0,041 | 0,160 | 0,100 |
