one.platform Single UAE computer socket mechanism (RJ45), shielded, cat.6, class E 455401
local index:
MJI007BERK
Catalog No:
455401
EAN code:
4011334437444
Price:
23,62 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Internet computer socket mechanism from the one.platform series, from the manufacturer Berker. The product catalog number is 455401.
FEATURES
- RJ45.
- Z angle of the output 45°.
- For RJ11, RJ12 and RJ45 plugs.
- Compatible with PoE+.
- Shield contact resistance: 100mΩ.< /li>
- Signal contact resistance: 20 mΩ.
- Galvanized housing.
- Without clamps.
- With LSA+ terminals.
- With 360° and cable clamp.
- Flexible cable entry.
- For order numbers 1407 .., 1408 .., 1468 .., 53 1407 ..< /strong>
- Color-coded according to EIA/TIA 568A and 568B.
- Category 6/Class E according to DIN EN 50173-1:2011-09.
- Transmission frequency up to 250 MHz.
Technical data
-
Category6
-
MaterialPlastic Metal
-
TypeInternet
-
Level of securityIP20
-
VersionShielded
-
VariantRJ45 (twisted pair)
-
Number of internet sockets1
-
ShapeSquare
-
DC rated voltage [V]72
-
FamilyONE.PLATFORM
-
TypeSocket mechanism
-
Mounting depth [mm]31
-
For the frame systemYes
-
PKWIU27.33.13.0
Other technical data
-
Surface mountingNo
-
Floor box/subfloor mountedYes
-
Assembly arrangementBasic element
-
With buses/couplingsYes
-
Category6
-
Shielded busesYes
-
Separate earthing connectionYes
-
Compatible with third-party coversYes
-
Outlet directionInclined
-
Degree of protection (IP)IP20
-
Colour codingYes
-
Device height70 mm
-
Duct installationYes
-
Type of fasteningScrewing
-
Type of connectorRJ45 8(8)
-
Suitable for number of connectors1
-
Connection typeLSA
-
Shielded housingYes
-
With label spaceNo
-
Separate strain reliefYes
-
With dust coverNo
-
Mechanical codingNo
-
Device width70 mm
-
Device depth45 mm
Bulk packaging
| A kind of package | Karton | Pakiet | Paleta | |
| Quantity | 1 pcs. | 10 pcs. | 120 pcs. | 1440 pcs. |
| Weight (kg) | 0,113 | 1,430 | 17,160 | 225,920 |
| Width (m) | 0,070 | 0,090 | 0,370 | 0,800 |
| Length (m) | 0,045 | 0,100 | 0,310 | 0,770 |
| Depth (m) | 0,070 | 0,365 | 0,360 | 1,200 |
