NILOE Cream stair connector 764601

local index:
MMS057LEGR
Catalog No:
764601
EAN code:
3414970684639
Manufacturer: LEGRAND
Number of keys: 1
Color: Beige
Shape: Square
Outlet

Stan produktu: Towar jest fabrycznie nowy, nieuszkodzony. Może nosić ślady długiego magazynowania.

Opakowanie: Towar może zostać dostarczony w opakowaniu zastępczym lub w lekko uszkodzonym oryginalnym opakowaniu.

Dostępność: Tylko w ilości dostępnej na magazynie.

Price:
1,30 €
gross / pcs.
(including VAT 23%)
Last lowest price: 1,30 € gross
Base price: 3,20 € gross -59%
Delivery in 3h
Accessible 46 pcs.
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
It is not possible to add more of this product to the cart. Goods at a promotional price can only be purchased in the quantity available in stock.
Add to clipboard
Print

Product description

Stair switchfrom the Niloe series, from the manufacturer Legrand. The product catalog number is 764601.



FEATURES

  • Mechanism with push button and mounting bracket.
  • To be equipped with a frame.
  • Fixed with screws or clips.
  • Can be converted into a LED illuminated switch using ref. 764521.



SERIES DESCRIPTION

Niloe is a traditional series of electrical installation accessories. The stair switch characterizes the features of this unique series.

Technical data

  • Number of keys
    1
  • Shape
    Square
  • Fixing
    claws Screws
  • Rated voltage [V]
    230
  • Type
    stairs
  • Level of security
    IP21
  • Accurate color
    Creamy
  • PKWIU
    27.33.11.0
  • Color
    Beige
  • Material
    Plastic
  • Installation
    Flush-mounted
  • Rated current [A]
    10
  • Family
    NILOE
  • Type
    Flush-mounted
  • For the frame system
    Yes

Other technical data

  • Wiring system
    Two-way switch
  • Assembly arrangement
    Basic element
  • Number of rockers
    1
  • Type of fastening
    Mounting with claw and screw
  • Material
    Plastic
  • Halogen free
    Yes
  • Surface finishing
    Glossy
  • RAL-number (similar)
    1013
  • Illumination
    Optional
  • Type of lighting
    Other
  • Nominal voltage
    250 V
  • Switching current for fluorescent lamps
    10 AX
  • Connection type
    Other
  • Device width
    75.8 mm
  • Device depth
    45.5 mm
  • Min. depth of built-in installation box
    30 mm
  • Method of operation
    Rocker/button
  • Push button switch
    No
  • Mounting method
    Flush-mounted
  • With mounting plate
    Yes
  • Material quality
    Thermoplastic
  • Surface protection
    Untreated
  • Colour
    Beige
  • Label space/information surface
    No
  • Function lighting
    Control and orientation
  • Suitable for degree of protection (IP)
    IP20
  • Rated current
    10 A
  • Feedback-signal contact
    No
  • Washing machine switch
    No
  • Device height
    75.8 mm
  • Built-in depth
    31 mm

Bulk packaging

A kind of package Pudełko Karton Paleta
Quantity 20 pcs. 100 pcs. 3500 pcs.
Weight (kg) 0,984 5,822 203,770
Volume (m3) 0,000 0,000 0,002
Width (m) 0,186 0,400 1,200
Length (m) 0,115 0,215 1,670
Depth (m) 0,386 0,600 1,000
