NILOE Cream single connector 764600

local index:
MMP020LEGR
Catalog No:
764600
EAN code:
3414970683908
Manufacturer: LEGRAND
Number of keys: 1
Color: Beige
Shape: Square
Outlet

Stan produktu: Towar jest fabrycznie nowy, nieuszkodzony. Może nosić ślady długiego magazynowania.

Opakowanie: Towar może zostać dostarczony w opakowaniu zastępczym lub w lekko uszkodzonym oryginalnym opakowaniu.

Dostępność: Tylko w ilości dostępnej na magazynie.

Price:
0,96 €
gross / pcs.
(including VAT 23%)
Last lowest price: 2,28 € gross
Base price: 2,36 € gross -59%
Delivery in 3h
Accessible 108 pcs.
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
It is not possible to add more of this product to the cart. Goods at a promotional price can only be purchased in the quantity available in stock.
Add to clipboard
Print

Product description

Single-pole switch from the  Niloe series, from the manufacturer Legrand. The product part number is 764600. Cream colored.

  • Mechanisms are supplied with nameplates and handles.
  • A choice of matching frames can be made.
  • Screws or snapó w.
  • Switching capacity: 10AX, 250V~.
  • Claws supplied with the mechanism
  • Can be converted into a switch with LED backlight using ref. 764521

Technical data

  • Number of keys
    1
  • Shape
    Square
  • Installation
    Flush-mounted
  • Rated current [A]
    10
  • Family
    NILOE
  • Type
    Flush-mounted
  • For the frame system
    Yes
  • Color
    Beige
  • Material
    Plastic
  • Rated voltage [V]
    230
  • Type
    Single
  • Level of security
    IP21
  • Accurate color
    Creamy
  • PKWIU
    27.33.11.0

Other technical data

  • Wiring system
    Off switch 1-pole
  • Assembly arrangement
    Basic element
  • Number of rockers
    1
  • Type of fastening
    Mounting with claw and screw
  • Material
    Plastic
  • Halogen free
    Yes
  • Surface finishing
    Glossy
  • RAL-number (similar)
    1013
  • Illumination
    Optional
  • Type of lighting
    Other
  • Nominal voltage
    250 V
  • Switching current for fluorescent lamps
    10 AX
  • Connection type
    Other
  • Device width
    75.8 mm
  • Device depth
    45.5 mm
  • Min. depth of built-in installation box
    30 mm
  • Method of operation
    Rocker/button
  • Push button switch
    No
  • Mounting method
    Flush-mounted
  • With mounting plate
    Yes
  • Material quality
    Thermoplastic
  • Surface protection
    Untreated
  • Colour
    Beige
  • Label space/information surface
    No
  • Function lighting
    Control and orientation
  • Suitable for degree of protection (IP)
    IP20
  • Rated current
    10 A
  • Feedback-signal contact
    No
  • Washing machine switch
    No
  • Device height
    75.8 mm
  • Built-in depth
    31 mm

Bulk packaging

A kind of package Pudełko Karton Paleta
Quantity 20 pcs. 100 pcs. 3500 pcs.
Weight (kg) 0,955 5,644 197,540
Volume (m3) 0,000 0,000 0,002
Width (m) 0,186 0,400 1,200
Length (m) 0,115 0,215 1,670
Depth (m) 0,386 0,600 1,000
