MUREVA STYL IP55 Anthracite roller shutter button MUR35042

local index:
MMO034SCHN
Catalog No:
MUR35042
EAN code:
3606480789465
Manufacturer: SCHNEIDER ELECTRIC
Depth [mm]: 40
Number of keys: 2
Color: Gray
Price:
17,01 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
2 weeks
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Shutter button from the Mureva Style series, from the manufacturer Schneider Electric. The product catalog number is MUR35042.



SERIES DESCRIPTION

Waterproof accessories from the Mureva Style series are designed for mounting lamps both surface-mounted and flush-mounted. It is distinguished by a high degree of protection IP55. The roller shutter button characterizes the features of this unique series.

Technical data

  • Depth [mm]
    40
  • Color
    Gray
  • Material
    Plastic
  • Installation
    Recessed Surface-mounted
  • Rated current [A]
    10
  • Family
    MUREVA STYLE
  • Width [mm]
    71
  • Version
    Single
  • Degree of mechanical protection
    IK07
  • Variant
    Two-position normally open
  • PKWIU
    27.33.11.0
  • Number of keys
    2
  • Shape
    Square
  • Fixing
    Screws
  • Rated voltage [V]
    230
  • Type
    Shutter
  • Level of security
    IP55
  • Type
    Recessed Surface-mounted
  • Height [mm]
    71
  • Backlight
    NO
  • Exact material
    SEBS ABS

Other technical data

  • Assembly arrangement
    Basic element
  • Method of operation
    Push button
  • Number of rockers
    1
  • Mounting method
    Surface mounted
  • Material
    Plastic
  • Surface protection
    Untreated
  • Colour
    Grey
  • Transparent
    No
  • Imprint
    Symbol "bell"
  • Suitable for degree of protection (IP)
    IP55
  • Rated current
    10 A
  • Device height
    76 mm
  • Model
    Single push button
  • Feedback-signal contact
    No
  • With lighting
    No
  • Type of fastening
    Engage (snap)
  • Material quality
    Thermoplastic
  • Surface finishing
    Matt
  • RAL-number (similar)
    7016
  • Label space/information surface
    Yes
  • With signal lamp
    No
  • Nominal voltage
    250 V
  • Device width
    76 mm
  • Device depth
    60 mm
