Manufacturer: HAGER
Depth [mm]: 42
Number of keys: 1
Color: Silver
Price:
3,90 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Accessible 107 pcs.
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Modern designs of multi-apartment buildings, office space in the standard segment and offices require the use of economic solutions that are very beneficial for the investor.

The quality of materials and the way they are made must meet the technological requirements, ensure a high aesthetic and functional standard.

The new series of lumina fittings offers investor-friendly, economical solutions dedicated to development construction. With the increase in the number of electrical receivers in our homes, the demand for the required power supply points increases. The ideal solution is a double modular power socket for multiple frames. Thanks to the compact design, it is possible to connect two power receivers to the socket at the same time, and to mount the socket in a combination of multiple frames. An ideal economic solution with a high aesthetic and functional standard.

Modern, aesthetic design

  • Timeless universal design of the series with a wide range of recipients in mind.< /li>

High-quality switch mechanisms with self-clamps

  • The mechanism of the lumina series switch provides switching capacity up to 10AX. As standard, the connectors are equipped with screwless terminals, ensuring quick and easy assembly.

Durable and solid mounting frame

  • The mounting frame is made of made of steel sheet guarantees secure assembly and is not damaged on uneven surfaces.

Sure and fast

  • Modular construction of the lumina series in system of multiple frames ensures quick and easy installation of accessories - a professional solution for electrical installers.

Universal 2-fold sockets for multiple frames

  • Economic solution for residential construction.

Additional security

  • Each element of the lumina series is packed in an individual package, thanks to which products are secured during transport and during storage at the construction site.

Technical data

  • Depth [mm]
    42
  • Color
    Silver
  • Material
    Plastic Metal
  • Rated voltage [V]
    230
  • Surface
    Gloss
  • Family
    LUMINA
  • Width [mm]
    71
  • Mounting depth [mm]
    26
  • Number of keys
    1
  • Number of poles
    1
  • Fixing
    Screw
  • Connection
    Quick Connect
  • Rated current [A]
    10
  • Level of security
    IP20
  • Height [mm]
    71
  • PKWIU
    27.33.11.0

Other technical data

  • Wiring system
    Other
  • Assembly arrangement
    Basic element
  • Number of rockers
    1
  • Type of fastening
    Mounting with claw and screw
  • Material
    Other
  • Halogen free
    Yes
  • Surface finishing
    Matt
  • RAL-number (similar)
    9006
  • Illumination
    No
  • Type of lighting
    Other
  • Nominal voltage
    250 V
  • Switching current for fluorescent lamps
    10 AX
  • Connection type
    Push-in clamp
  • Device width
    71 mm
  • Device depth
    42 mm
  • Min. depth of built-in installation box
    35 mm
  • Method of operation
    Rocker/button
  • Push button switch
    No
  • Mounting method
    Flush-mounted
  • With mounting plate
    Yes
  • Material quality
    Other
  • Surface protection
    Untreated
  • Colour
    Silver
  • Label space/information surface
    No
  • Function lighting
    Other
  • Suitable for degree of protection (IP)
    IP20
  • Rated current
    10 A
  • Feedback-signal contact
    No
  • Washing machine switch
    No
  • Device height
    71 mm
  • Built-in depth
    26 mm

Bulk packaging

A kind of package Karton Pakiet Paleta
Quantity 1 pcs. 12 pcs. 120 pcs. 2400 pcs.
Weight (kg) 0,063 0,780 7,800 197,000
Width (m) 0,071 0,215 0,475 1,200
Length (m) 0,041 0,090 0,235 1,090
Depth (m) 0,071 0,185 0,390 0,800
