Name: Laser distance sensor DRL-60-230-1 White, for ø60 box, motion sensor for controlling lighting on stairs and corridors
Brand: F&F
SKU: MWC003FIFQ
Price: 514.76 PLN
Availability: BackOrder

Інші технічні дані

Model

Movement sensor
Constant light control

Yes
Forced switch on

Yes
Animal zone

No
Background monitoring

No
Scan angle

10 °
Staircase light controller

Yes
Max. reach sideways

0.5 m
Max. reach frontally

2 m
Suitable for wireless transmission

No
With remote control

No
Response value luminosity adjustable

Yes
Teach-function for response value luminosity

No
Mounting method

Flush-mounted
Suitable for wall mounting

Yes
Material

Metal
Halogen free

No
Surface finishing

Matt
Colour

White
Transparent

No
Impact strength

IK00
Frequency

50 ... 50 Hz
Min. switch-on time

1 s
Switch-off delay

5 s
Detection angle horizontal

-18 ... 18 °
Max. switching power

2000 W
Suitable for C-load

No
Number of switching zones

1
Min. starting current

0.1 A
Substation input

No
With acoustic sensor

No
Height

80 mm
Diameter

60 mm
Built-in depth

30 mm
Built-in diameter

0 mm
With connection cable

No
Compatible with Apple HomeKit

No
Compatible with Amazon Alexa

No

With DALI interface

No
HVAC-control

No
Forced switch off

No
Creep-under protection

No
Networkable

No
Optimum mounting height

0.5 m
Bridging switch

No
Max. presence range

1 m²
Diameter reach on floor

1 m
Remote operation

No
Response value sensitivity adjustable

Yes
With signal unit

Yes
Dim function with dimmer basic element

Yes
Suitable for ceiling mounting

No
Connection type

Screwed terminal
Material quality

Aluminium
Surface protection

Sand-cast
Anti-bacterial treatment

No
RAL-number (similar)

9003
Degree of protection (IP)

IP20
Voltage type

AC
Nominal voltage

165.00000000 ... 265.00000000 V
Max. duty cycle

10 min
Switching-on delay

5 s
Response value luminosity

2.00000000 ... 500.00000000 lx
Max. switching power LED

100 W
Temperature

-10 ... 45 °C
Max. starting current

8 A
Control current

0 mA
With alarm function

No
Width

0 mm
Depth

31.5 mm
Built-in width

48 mm
Built-in length

35 mm
Min. depth of built-in installation box

35 mm
Connection cable length

0 mm
Compatible with Google Assistant

No
IFTTT support available

No

Laser distance sensor DRL-60-230-1 White, for ø60 box, motion sensor for controlling lighting on stairs and corridors DRL-60-230-1
