INTEGRO FLOW/PURE Push-button switch, normally open, stainless steel, varnished 936712524

local index:
MMZ043BERK
Catalog No:
936712524
EAN code:
4011334334699
Manufacturer: BERKER
Depth [mm]: 24.1
Number of keys: 1
Color: Silver
Price:
25,40 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 10 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Switch pushbutton, normally open, from the Berker Integro Flow/Pure series, from the manufacturer Berker. The product catalog number is 936712524.



FEATURES

  • With screw terminals.



SERIES DESCRIPTION

Berker Integro Flow with its minimalist design, quick and easy installation makes the series an ideal solution for use in kitchen furniture in sanitary industry and everywhere where compact design and comprehensive functionality are required.

Technical data

  • Depth [mm]
    24.1
  • Color
    Silver
  • Material
    Plastic
  • Rated voltage [V]
    230
  • Type
    Short
  • Level of security
    IP44
  • Type
    Flush-mounted
  • Height [mm]
    55.5
  • Surface finish
    matte
  • Backlight
    NO
  • Variant
    Ordinary
  • Exact material
    Thermoplastic
  • Number of keys
    1
  • Shape
    Round
  • Installation
    Flush-mounted
  • Rated current [A]
    10
  • Family
    INTEGRO FLOW INTEGRA PURE
  • Width [mm]
    55.5
  • Version
    Confident
  • Surface protection
    varnishing
  • Accurate color
    Stainless steel
  • Terminal type
    Threaded
  • For the frame system
    Yes
  • PKWIU
    27.33.11.0

Other technical data

  • Assembly arrangement
    Basic element with central cover plate
  • Method of operation
    Rocker
  • Number of modules (module system)
    0
  • Nominal voltage
    250 V
  • With lighting
    No
  • Feedback-signal contact
    No
  • Type of fastening
    Screw mounting
  • Material quality
    Thermoplastic
  • Anti-bacterial treatment
    No
  • Surface finishing
    Matt
  • RAL-number (similar)
    9022
  • Label space/information surface
    No
  • Suitable for degree of protection (IP)
    IP44
  • Device height
    55.5 mm
  • Min. depth of built-in installation box
    13 mm
  • Model
    Single push button
  • Number of rockers
    1
  • Number of poles
    1
  • Rated current
    10 A
  • With signal lamp
    No
  • Mounting method
    Built-in installation
  • Material
    Plastic
  • Halogen free
    Yes
  • Surface protection
    Lacquered
  • Colour
    Stainless steel
  • Transparent
    No
  • Imprint
    None
  • Device width
    55.5 mm
  • Device depth
    24.1 mm

Bulk packaging

A kind of package Karton Pakiet Paleta
Quantity 1 pcs. 10 pcs. 100 pcs. 5000 pcs.
Weight (kg) 0,030 0,350 3,500 175,000
Width (m) 0,056 0,130 - 0,800
Length (m) 0,024 0,060 - 1,690
Depth (m) 0,056 0,200 - 1,200
