INTEGRO FLOW/PURE Illuminated push-button switch with red lens anthracite matte 937722505

Name: INTEGRO FLOW/PURE Illuminated push-button switch with red lens anthracite matte
Brand: BERKER
SKU: MMZ053BERK
Price: 32.64 PLN

local index:

MMZ053BERK

Catalog No:

937722505

EAN code:

4011334240280

INTEGRO FLOW/PURE Illuminated push-button switch with red lens anthracite matte

Click on the photo to enlarge

Manufacturer: BERKER

Depth [mm]: 24.1

Number of keys: 1

Color: Graphite

See full description

Price:

32,64 €

gross / pcs.

(including VAT 23%)

Delivery in 3h

up to 10 weeks (business days)

Pickup in 1h

Quantity pcs.

(multiplicity:

)

Add to clipboard

Ask about the product

Product description Technical data Bulk packaging

Product description

Illuminated push-button switch with red lens, Berker Integro Flow/Pure series, from Berker manufacturer. Number product catalog is 937722505. Anthracite.

FEATURES

With screw terminals.< /li>
For backlight connection and backlight control connection.
With built-in fluorescent lamp.
Glow tube current: 0.9mA.
Instructions: When using several glow plugs, the lamp current may cause the relay/pulse switch to malfunction. Solution: Run a neutral wire or connect a 230V capacitor in parallel to the coil (1 µF for every 10mA of fluorescent lamp current).

< h3>SERIES DESCRIPTION

Berker Integro Flow with its minimalist design, quick and easy installation makes the series an ideal solution for use in kitchen furniture, in the sanitary industry and everywhere where compact design and versatile functionality are required.

Technical data

Depth [mm]

24.1
Color

Graphite
Material

Plastic
Rated voltage [V]

230
Type

Short
Level of security

IP44
Type

Flush-mounted
Height [mm]

55.5
Accurate color

Anthracite
Terminal type

Threaded
For the frame system

Yes
Backlight type

Jaleniówka
PKWIU

27.33.11.0

Number of keys

1
Shape

Round
Installation

Flush-mounted
Rated current [A]

10
Family

INTEGRO FLOW INTEGRA PURE
Width [mm]

55.5
Version

Confident
Surface finish

matte
Backlight

Yes
Variant

Ordinary
Exact material

Thermoplastic
Backlight color

Red

Other technical data

Assembly arrangement

Basic element with central cover plate
Method of operation

Rocker
Number of modules (module system)

0
Nominal voltage

250 V
With lighting

Yes
Feedback-signal contact

No
Type of fastening

Screw mounting
Material quality

Thermoplastic
Anti-bacterial treatment

No
Surface finishing

Matt
RAL-number (similar)

7021
Label space/information surface

No
Suitable for degree of protection (IP)

IP44
Device height

55.5 mm
Min. depth of built-in installation box

13 mm

Model

Single push button
Number of rockers

1
Number of poles

1
Rated current

10 A
With signal lamp

No
Mounting method

Built-in installation
Material

Plastic
Halogen free

Yes
Surface protection

Untreated
Colour

Anthracite
Transparent

No
Imprint

None
Device width

55.5 mm
Device depth

24.1 mm

Bulk packaging

A kind of package		Karton	Pakiet	Paleta
Quantity	1 pcs.	10 pcs.	100 pcs.	2400 pcs.
Weight (kg)	0,033	0,385	4,230	124,520
Width (m)	0,056	0,140	0,315	0,800
Length (m)	0,024	0,065	0,220	1,050
Depth (m)	0,056	0,205	0,365	1,200
