Double socket-outlet (module), 230V, metallic satin BMG2M.01/29

Name: Double socket-outlet (module), 230V, metallic satin
Brand: KONTAKT-SIMON
SKU: MEE147KONT
Price: 6.45 PLN

local index:

MEE147KONT

Catalog No:

BMG2M.01/29

EAN code:

5902787813239

Double socket-outlet (module), 230V, metallic satin

Click on the photo to enlarge

Manufacturer: KONTAKT-SIMON

Halogen free: Yes

Depth [mm]: 45

Number of sockets: 2

See full description

Price:

6,45 €

gross / pcs.

(including VAT 23%)

Delivery in 3h

up to 2 weeks (business days)

Pickup in 1h

Quantity pcs.

(multiplicity:

)

Add to clipboard

Ask about the product

Product description Technical data Bulk packaging Files to download

Product description

Socket from the Simon Basic series, from the manufacturer Contact Simon. The product part number is BMG2M.01/29.

FEATURES

Double.
Ungrounded.
Screw terminals.
To be equipped with frame .
Colour satin, metallic.
Rated current 16A.
Rated voltage 230V.
Ingress protection IP20.
flush mounting.
Dimensions: 80 x 75 mm (height x width).
Made of PC.

SERIES DESCRIPTION

Functionality and classic look are the hallmarks of the Simon Basic series, which will work in any space. The color palette makes it possible to subtly integrate switches and sockets into the design of an apartment, premises, living room or office.

Technical data

Halogen free

Yes
Number of sockets

2
Shape

Rectangular
Fixing

claws Screws
Rated voltage [V]

230
Type

Electric
Level of security

IP20
Type

Flush-mounted
Height [mm]

80
Surface finish

matte
Backlight

NO
Terminal type

Threaded
Shutters of current paths

NO
For the frame system

Yes
PKWIU

27.33.13.0

Depth [mm]

45
Color

Silver
Material

Plastic
Installation

Flush-mounted
Rated current [A]

16
Family

SIMON BASIC
Width [mm]

75
Ground

Lack
Surface protection

varnishing
Accurate color

Satin metallic
Mounting depth [mm]

21
Standard

European
On the DATA key

NO
Exact material

PC

Other technical data

Number of units

2
Mounting method

Flush-mounted
Material quality

Thermoplastic
Surface finishing

Matt
Frequency

50 ... 60 Hz

Connection type

Screwed terminal
Material

Plastic
Surface protection

Lacquered
Nominal voltage

250 V
Suitable for degree of protection (IP)

IP20

Bulk packaging

A kind of package		Paczka	Karton
Quantity	1 pcs.	1 pcs.	10 pcs.
Weight (kg)	0,068	0,068	0,764
Width (m)	0,080	0,110	0,190
Length (m)	0,075	0,050	0,230
Depth (m)	0,045	0,160	0,100
