86426
0
Double-pole switch (module) 16A, 250V, screw terminals, cream DW2A.01/41
local index:
MMD049KONT
Catalog No:
DW2A.01/41
EAN code:
5902787822910
Price:
7,79 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Double-pole switch from the Simon 54 series, from the manufacturer Contact Simon. The product catalog number is DW2A.01/41.
FEATURES
- Module without frame.< /li>
- Screw terminals.
- Backlight optional, not included.
- Rocker switch.
- Toggle switch.
- To be obtained splash-proof class IP44, use a frame gasket.
SERIES DESCRIPTION
Simon 54 is a series of modern accessories installation, distinguished by reliable and easy-to-install mechanisms and a variety of colors.
Technical data
-
Halogen freeYes
-
Number of keys1
-
ShapeSquare
-
Fixingclaws Screws
-
Rated voltage [V]230
-
TypeBipolar
-
Level of securityIP20
-
Width [mm]75
-
Height [mm]75
-
Surface finishShiny
-
BacklightNO
-
Terminal typeThreaded
-
Exact materialPC
-
Depth [mm]41
-
ColorBeige
-
MaterialPlastic
-
InstallationFlush-mounted
-
Rated current [A]16
-
FamilySimon 54
-
Symbol0-1
-
TypeFlush-mounted
-
Surface protectionNatural
-
Accurate colorCreamy
-
Mounting depth [mm]26
-
For the frame systemYes
-
PKWIU27.33.11.0
Other technical data
-
Wiring system2-pole switch
-
Assembly arrangementBasic element with central cover plate
-
MaterialPlastic
-
Surface protectionUntreated
-
ColourKremowy
-
Nominal voltage250 V
-
Connection typeScrewed terminal
-
Method of operationRocker/button
-
Mounting methodFlush-mounted
-
Material qualityThermoplastic
-
Surface finishingGlossy
-
Suitable for degree of protection (IP)IP20
-
Switching current for fluorescent lamps16 AX
Manufacturer details
-
ManufacturerKONTAKT - SIMON S.A.
-
Address43-500 Czechowice-Dziedzice Bestwińska 21
-
Phone number
-
E-mail
-
Tax identification number6520005366
-
GLN5900009931105
Bulk packaging
| A kind of package | Paczka | Karton | |
| Quantity | 1 pcs. | 1 pcs. | 10 pcs. |
| Weight (kg) | 0,065 | 0,065 | 0,739 |
| Width (m) | 0,075 | 0,110 | 0,190 |
| Length (m) | 0,075 | 0,045 | 0,230 |
| Depth (m) | 0,041 | 0,160 | 0,100 |
