DATA socket (module), 230V, metallic stainless steel BMGD1.01/21

Name: DATA socket (module), 230V, metallic stainless steel
Brand: KONTAKT-SIMON
SKU: MEE164KONT
Price: 8.30 PLN

local index:

MEE164KONT

Catalog No:

BMGD1.01/21

EAN code:

5902787814632

DATA socket (module), 230V, metallic stainless steel

Click on the photo to enlarge

Manufacturer: KONTAKT-SIMON

Halogen free: Yes

Depth [mm]: 40.5

Number of sockets: 1

See full description

Price:

8,30 €

gross / pcs.

(including VAT 23%)

Delivery in 3h

up to 2 weeks (business days)

Pickup in 1h

Quantity pcs.

(multiplicity:

)

Add to clipboard

Ask about the product

Product description Technical data Bulk packaging Files to download

Product description

Socket from the Simon Basic series, from the manufacturer Contact Simon. The product part number is BMGD1.01/21.

FEATURES

Single.
DATE, with authorization key.
Grounded, ground pin.

Screw terminals

To be equipped with a frame.
Current paths' shutters .
Color inox, metallic.
Rated current 16A.
Rated voltage 230V.
Ingress protection IP20.
flush mounting.
Dimensions: 75 x 75 mm (HxW).
Made of PC.

DESCRIPTION SERIES

Functionality and classic look are the hallmarks of the Simon Basic series, which will work in any space. The color palette makes it possible to subtly integrate switches and sockets into the design of an apartment, premises, living room or office.

Technical data

Halogen free

Yes
Number of sockets

1
Shape

Square
Fixing

claws Screws
Rated voltage [V]

230
Type

Electric
Level of security

IP20
Type

Flush-mounted
Height [mm]

75
Surface finish

matte
Backlight

NO
Terminal type

Threaded
Shutters of current paths

Yes
For the frame system

Yes
PKWIU

27.33.13.0

Depth [mm]

40.5
Color

Silver
Material

Plastic
Installation

Flush-mounted
Rated current [A]

16
Family

SIMON BASIC
Width [mm]

75
Ground

Hurt
Surface protection

varnishing
Accurate color

Metallized stainless steel
Mounting depth [mm]

28
Standard

European
On the DATA key

Yes
Exact material

PC

Other technical data

Number of units

1
Mounting method

Flush-mounted
Material quality

Thermoplastic
Surface finishing

Matt
Frequency

50 ... 60 Hz

Connection type

Screwed terminal
Material

Plastic
Surface protection

Lacquered
Nominal voltage

250 V
Suitable for degree of protection (IP)

IP20

Bulk packaging

A kind of package		Paczka	Karton
Quantity	1 pcs.	1 pcs.	10 pcs.
Weight (kg)	0,079	0,079	0,884
Width (m)	0,075	0,110	0,230
Length (m)	0,075	0,046	0,230
Depth (m)	0,041	0,160	0,100
