CELIANE - 2x2P+E double socket-outlet for installation in a single box 067137

Lokaler Index:

MJE012LEGR

Katalognummer:

067137

EAN-Code:

3245060671372

CELIANE - 2x2P+E double socket-outlet for installation in a single box

Klicken Sie auf das Foto, um es zu vergrößern

Hersteller: LEGRAND

Number of sockets: 2

Shape: Square

Fixing: claws | Screws

Siehe vollständige Beschreibung

zł

gross / stk. (inklusive MwSt 23%)

Dostępne bis zu einer Woche

Auf Bestellung

Wählen Sie Ihren Großhändler

Wählen Sie

Menge stk. (mehrere: 1 )

Produktbeschreibung Technische Daten Hersteller-Details Großpackungen

Produktbeschreibung

Socket mechanism from the Celiane series, from the manufacturer Legrand. The product catalog number is 067137.

FEATURES

2 x 2P+Z.

Double socket.

Grounded; grounding pin.

Auto spring terminals.

Rated current 16 A.

Rated voltage 230 V.

To be mounted in a single box using claws or screws.

To be equipped with badges ref. 068647 (white), 068757 (sand), 068937 (graphite), 068947 (titanium).

SERIES DESCRIPTION

< strong>Celiane is a series of modern electrical installation equipment, created by a universal combination of circle and rectangle shapes. Electric socket mechanism characterizes the features of this unique series.

Technische Daten

Number of sockets

2
Fixing

claws Screws
Rated voltage [V]

230
Type

Electric
Level of security

IP20
Ground

Hurt
Terminal type

Threadless
Shutters of current paths

NO
For the frame system

NO

Shape

Square
Installation

Flush-mounted
Rated current [A]

16
Family

CELIANE
Type

Socket mechanism
Backlight

NO
Standard

European
On the DATA key

NO
PKWIU

27.33.13.0

Weitere technische Daten

Model

Earthing pin
Protective contact

Round
Number of active contacts (flat)

0
Assembly arrangement

Basic element
Number of ports USB-A

0
Number of socket outlets

2
Number of socket outlets switchable

0
Imprint/indication

None
With hinged lid

No
Label space/information surface

No
RAL-number (similar)

7016
Transparent

No
Eject-mechanism

No
With function lighting

No
Over voltage protection

No
With miniature fuse

No
Mounting method

Module frame
Material

Plastic
Halogen free

Yes
Surface finishing

Matt
With loop through function

Yes
Rotated central insert

No
Nominal voltage

250 V
Suitable for degree of protection (IP)

IP20
Device width

71 mm
Device depth

38 mm
Compatible with Amazon Alexa

No
IFTTT support available

No
With built-in bluetooth speaker

No

Concurrently switching neutral conductor

No
Number of active contacts (round)

4
Number of active contacts (square)

0
With signal lamp

No
Number of ports USB-C

0
Number of modules (module system)

2
Number of phases

1
Connection type

Push-in clamp
With enhanced contact protection

Yes
Colour

Grey
Metallic colour

No
Lockable

No
Insulated mounting

No
With orientation lighting

No
Fault current protection

No
Special power supply

None
Type of fastening

Snap mounting (engagement)
Material quality

Thermoplastic
Surface protection

Untreated
Anti-bacterial treatment

No
With on/off switch

No
Nominal current

16 A
Frequency

50 ... 60 Hz
Impact strength

IK04
Device height

71 mm
Compatible with Apple HomeKit

No
Compatible with Google Assistant

No
With Wi-Fi signal repeater

No
For heavy conditions according to VDE

No

Hersteller-Details

Hersteller

Legrand Polska Sp. z o.o.
Adresse

57-200 Ząbkowice Śląskie Waryńskiego 20 Polska
E-Mail

info@legrand.com.pl

Großpackungen

Eine Art Paket	Pudełko	Karton	Paleta
Menge	10 stk.	50 stk.	3500 stk.
Gewicht (kg)	0,727	3,921	274,470
Volumen (m3)	0,004	0,023	1,926
Breite (m)	0,175	0,298	1,200
Länge (m)	0,055	0,195	1,605
Tiefe (m)	0,395	0,398	1,000
