Candlestick connector, aluminum colour 770105
local index:
MMT025LEGR
Catalog No:
770105
EAN code:
3245067701058
Price:
5,34 €
gross / pcs.
(including VAT 23%)
Last lowest price:
12,67 € gross
Price history for this product
1. 5,34 € gross / pcs.
2. Last lowest price:
12,67 €
3. Base price:
13,43 €
-60%
1. How much does this product cost today
2. Lowest price in the last 30 days
3. The base price of the product
Base price:
13,43 € gross
-60%
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
It is not possible to add more of this product to the cart. Goods at a promotional price can only be purchased in the quantity available in stock.
Add to clipboard
Print
Ask about the product
Product description
Candlestick connector from the Valena series, from the manufacturer Legrand. The product part number is 770105.
FEATURES
- Borderless module .
- Automatic Spring Clamps.
- Color Aluminum.
- Rated Current 10 AX.
- Rated voltage 230 V.
- Mounting flush.
- Mechanism complete with keys and a metal holder.
- Mounting with claws or screws.
- The product is compatible with fluorescent lamps.
Technical data
-
Number of keys2
-
ShapeSquare
-
Fixingclaws Screws
-
Rated voltage [V]230
-
TypeCandlestick
-
Level of securityIP20
-
Accurate colorAluminum
-
Terminal typeThreadless
-
PKWIU27.33.11.0
-
ColorSilver
-
MaterialPlastic
-
InstallationFlush-mounted
-
Rated current [A]10
-
FamilyVALENA
-
TypeFlush-mounted
-
BacklightNO
-
For the frame systemYes
Other technical data
-
Wiring systemOff switch 1-pole
-
Assembly arrangementBasic element with central cover plate
-
Number of rockers2
-
Type of fasteningMounting with claw and screw
-
MaterialPlastic
-
Halogen freeYes
-
Surface finishingGlossy
-
RAL-number (similar)7040
-
IlluminationNo
-
Type of lightingOther
-
Nominal voltage250 V
-
Switching current for fluorescent lamps10 AX
-
Connection typeOther
-
Device width71 mm
-
Device depth37 mm
-
Min. depth of built-in installation box30 mm
-
Method of operationRocker/button
-
Push button switchNo
-
Mounting methodFlush-mounted
-
With mounting plateYes
-
Material qualityThermoplastic
-
Surface protectionLacquered
-
ColourAluminium
-
Label space/information surfaceNo
-
Function lightingOther
-
Suitable for degree of protection (IP)IP31
-
Rated current10 A
-
Feedback-signal contactNo
-
Washing machine switchNo
-
Device height71 mm
-
Built-in depth21 mm
Bulk packaging
| A kind of package | Pudełko | Karton | Paleta |
| Quantity | 10 pcs. | 100 pcs. | 1000 pcs. |
| Weight (kg) | 0,806 | 8,360 | 83,600 |
| Volume (m3) | 0,000 | 0,000 | 0,001 |
| Width (m) | 0,175 | 0,386 | 1,200 |
| Length (m) | 0,055 | 0,300 | 0,549 |
| Depth (m) | 0,395 | 0,405 | 1,000 |
